Single Row Deep Groove Ball Bearings 6314-RS2Z/C4S1VT441

Single Row Deep Groove Ball Bearings 6314-RS2Z/C4S1VT441

The 6314-RS2Z/C4S1VT441 is a single-row deep groove ball bearing with a 70mm bore and 150mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2338 lbf and runs smoothly at speeds up to 4500 RPM.

Its shielded design keeps dirt out while maintaining smooth operation, and the chrome steel cage adds durability. The bearing operates well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 2530g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6314-RS2Z/C4S1VT441
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 35 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 200 °C
  • Dynamic Radial Load 2338 lbf
  • Static Radial Load 15332 lbf
  • Max Speed 4500 rpm
  • Weight 2530 g
  • price（$） 78.444
Single Row Deep Groove Ball Bearings 6314-RS2Z/C4S1VT441 dimension drawing
Download DWG Download PDF

Features

What Makes 6314-RS2Z/C4S1VT441 Bearing Suitable for High-Temperature Applications?

6314-RS2Z/C4S1VT441 Bearing operates effectively in temperatures ranging from -30°C to 200°C, making it versatile for various environments.
Its chrome steel construction ensures durability and resistance to wear, even under high thermal stress.
The shielded design protects against contaminants, maintaining smooth operation in challenging conditions.
With a dynamic radial load capacity of 2338 lbf, it delivers reliable performance in demanding applications.

Application

Industrial Uses of 6314-RS2Z/C4S1VT441 Bearing
6314-RS2Z/C4S1VT441 Bearing is commonly used in industrial machinery, such as pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6314-RS2Z/C4S1VT441 Bearing supports components like alternators and water pumps, providing reliable performance under radial loads. Its C4 clearance makes it suitable for applications with thermal expansion concerns.

For automation systems, 6314-RS2Z/C4S1VT441 Bearing is a solid choice for robotic arms and conveyor belts, where smooth operation is essential. The wide temperature range allows it to perform well in various conditions.

In household appliances like washing machines, 6314-RS2Z/C4S1VT441 Bearing offers quiet and efficient operation. Its shielded design helps extend the lifespan by reducing dust and debris ingress.
