Single Row Deep Groove Ball Bearings 6306 TC/C782

Single Row Deep Groove Ball Bearings 6306 TC/C782

The 6306 TC/C782 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6002 lbf and operates smoothly at speeds up to 9600 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 346g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6306 TC/C782
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6002 lbf
  • Static Radial Load 3372 lbf
  • Max Speed 9600 rpm
  • Weight 346 g
  • price（$） 73.215
Single Row Deep Groove Ball Bearings 6306 TC/C782 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6306 TC/C782 Bearing

6306 TC/C782 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 6002 lbf.

Its single-row deep groove design ensures smooth operation and efficient load distribution.

The open seal type allows for easy maintenance and lubrication, enhancing its versatility.

With a maximum speed of 9,600 rpm, it delivers reliable performance in various applications.

Application

Common Applications of 6306 TC/C782 Bearing
The 6306 TC/C782 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, making it suitable for high-speed operations.

In automotive applications, 6306 TC/C782 Bearing fits well in wheel hubs and alternators, providing smooth rotation under varying loads. The chrome steel construction offers durability, even in demanding driving conditions.

For home appliances like washing machines, 6306 TC/C782 Bearing helps reduce noise and vibration during operation. Its metric sizing ensures compatibility with a range of European and Asian appliance models.

Where Is 6306 TC/C782 Bearing Used?
You’ll often find 6306 TC/C782 Bearing in conveyor systems, where its ability to handle radial loads keeps production lines running smoothly. The ABEC 1 tolerance ensures consistent performance without unnecessary precision costs.

In robotics, 6306 TC/C782 Bearing supports joint movements, thanks to its balanced load distribution. The chrome steel cage adds extra durability, making it a reliable choice for automated systems.

Built for Heavy-Duty Use: 6306 TC/C782 Bearing
The 6306 TC/C782 Bearing excels in agricultural equipment, such as tractors, where its robust design handles rough terrain and heavy loads. Its temperature range also makes it suitable for outdoor use.

In HVAC systems, 6306 TC/C782 Bearing ensures quiet and efficient fan operation. The open seal type allows for easy maintenance, extending the bearing’s service life.

Light-Duty vs Heavy-Duty: Best Uses for 6306 TC/C782 Bearing
For light-duty tasks like office printers, 6306 TC/C782 Bearing provides smooth paper feed mechanisms. Its compact size and weight make it ideal for space-constrained devices.

In heavy-duty scenarios like construction machinery, 6306 TC/C782 Bearing withstands high radial loads without compromising performance. The chrome steel rings and balls ensure long-term reliability.
