Single Row Deep Groove Ball Bearings 6213 Y/C782

Single Row Deep Groove Ball Bearings 6213 Y/C782

The 6213 Y/C782 is a single-row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 12859 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 979g, it offers a balance of strength and manageability. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6213 Y/C782
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 12859 lbf
  • Static Radial Load 9015 lbf
  • Max Speed 5300 rpm
  • Weight 979 g
  • price（$） 107.001
Single Row Deep Groove Ball Bearings 6213 Y/C782 dimension drawing
Download DWG Download PDF

Features

How Does 6213 Y/C782 Bearing Reduce Friction?

6213 Y/C782 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while minimising friction during operation.
With a dynamic radial load capacity of 12,859 lbf, it handles demanding applications efficiently.
Its open design allows for easy maintenance, and it operates reliably within a temperature range of -30°C to 120°C.

Application

Industrial Uses of 6213 Y/C782 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The chrome steel construction ensures durability in demanding environments.

Where Is 6213 Y/C782 Bearing Used?
You’ll find it in automotive applications such as alternators and wheel hubs, thanks to its reliable performance under varying speeds. Its open seal design allows for easy lubrication and maintenance.

Built for Heavy-Duty Use: 6213 Y/C782 Bearing
In automation systems, this bearing supports robotic arms and conveyor belts, providing smooth operation. The ABEC 1 tolerance makes it suitable for general precision requirements.

Medical vs Industrial: Where 6213 Y/C782 Bearing Excels
While it’s robust enough for industrial gear, its consistent performance also suits medical devices like centrifuges. The temperature range ensures reliability in diverse operating conditions.

Perfect Fit for Automation: 6213 Y/C782 Bearing
Ideal for 3D printers and CNC machines, this bearing offers quiet and efficient operation. The static radial load capacity ensures stability during prolonged use.
