Single Row Deep Groove Ball Bearings 6206/VK2410

Single Row Deep Groove Ball Bearings 6206/VK2410

The 6206/VK2410 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4384 lbf and can spin at speeds of 11000 RPM.
Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a reliable replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are typical.
Weighing 199g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206/VK2410
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 199 g
Single Row Deep Groove Ball Bearings 6206/VK2410 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6206/VK2410 Bearing

6206/VK2410 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4384 lbf.
Its single-row deep groove design ensures smooth operation and efficient load distribution.

The open seal type allows for easy maintenance and lubrication, enhancing its versatility.
With a maximum speed of 11,000 rpm, it delivers reliable performance in various applications.

6206/VK2410 Bearing operates in temperatures from -30°C to 120°C, making it suitable for diverse environments.
The chrome steel cage ensures durability and reduces wear over time.

Its ABEC 1 tolerance class provides consistent precision for general industrial use.
The lightweight design at 199 grams makes it easy to handle without compromising strength.

Application

Industrial Uses of 6206/VK2410 Bearing
The 6206/VK2410 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design allows for easy lubrication, making it suitable for high-speed applications.

Where Is 6206/VK2410 Bearing Used?
In automotive applications, 6206/VK2410 Bearing can be found in alternators and wheel hubs, providing smooth rotation under radial loads. The chrome steel construction offers durability in demanding conditions.

Perfect Fit for Automation: 6206/VK2410 Bearing
For automation systems, 6206/VK2410 Bearing works well in robotic arms and conveyor belts, thanks to its balanced load handling. The ABEC 1 tolerance ensures consistent performance in precision tasks.

Light-Duty vs Heavy-Duty: Best Uses for 6206/VK2410 Bearing
In light-duty applications like household fans, 6206/VK2410 Bearing offers quiet operation and longevity. For heavier tasks, such as industrial gearboxes, it maintains stability under continuous use.

Medical vs Industrial: Where 6206/VK2410 Bearing Excels
While 6206/VK2410 Bearing is versatile in industrial settings, its precision also makes it suitable for medical devices like lab equipment. The temperature range ensures reliability in various environments.
