Single Row Deep Groove Ball Bearings 6200-Z/MT

Single Row Deep Groove Ball Bearings 6200-Z/MT

The 6200-Z/MT is a compact single-row deep groove ball bearing with a 10mm bore and 30mm outer diameter, crafted from sturdy chrome steel. Its shielded design keeps dirt out while maintaining smooth operation.

This bearing handles radial loads up to 1147 lbf and spins efficiently at speeds up to 24,000 RPM. It performs reliably in temperatures ranging from -30°C to 120°C.

With a chrome steel cage, it offers durability and consistent performance. The ABEC 1 tolerance ensures decent precision for general applications.

Ideal for small motors, pumps, or appliances where space is limited. Weighing just 32g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6200-Z/MT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 30 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 24000 rpm
  • Weight 32 g
Single Row Deep Groove Ball Bearings 6200-Z/MT dimension drawing
Download DWG Download PDF

Features

How Does 6200-Z/MT Bearing Reduce Friction?

6200-Z/MT Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its shielded construction helps keep contaminants out while maintaining low friction.
Made from chrome steel, 6200-Z/MT Bearing resists wear and operates quietly at high speeds.
With a dynamic radial load capacity of 1147 lbf, it balances durability and efficiency in various applications.

Application

Common Applications of 6200-Z/MT Bearing
In industrial settings, 6200-Z/MT Bearing is commonly used in electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

Where Is 6200-Z/MT Bearing Used?
You’ll often find 6200-Z/MT Bearing in automotive applications like alternators and small gearboxes, thanks to its reliable radial load handling. Its compact size makes it a great fit for tight spaces.

Ideal for Precision: 6200-Z/MT Bearing
For small machinery and tools, 6200-Z/MT Bearing offers smooth operation with minimal maintenance. The ABEC 1 tolerance ensures consistent performance without overcomplicating the design.

Automotive vs Industrial: Applications of 6200-Z/MT Bearing
In cars, 6200-Z/MT Bearing handles radial loads in components like fans and pulleys. In factories, it’s a go-to for conveyor systems and light-duty machinery.

Perfect Fit for Automation: 6200-Z/MT Bearing
Robotic arms and small automated devices benefit from 6200-Z/MT Bearing’s balance of speed and load capacity. The shielded seals help extend service life in dusty environments.
