Single Row Deep Groove Ball Bearings 609-2Z/C3LHT23

Single Row Deep Groove Ball Bearings 609-2Z/C3LHT23

The 609-2Z/C3LHT23 is a compact single-row deep groove ball bearing, measuring 9mm by 24mm by 7mm. Made from chrome steel, it’s built to handle radial loads up to 642 lbf and spins smoothly at speeds up to 32,000 RPM.

Its shielded design keeps dirt out while the C3 radial clearance allows for slight misalignment. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for small motors, fans, or appliances where space is limited.

Weighing just 14.7g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 609-2Z/C3LHT23
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 642 lbf
  • Static Radial Load 260 lbf
  • Max Speed 32000 rpm
  • Weight 14.7 g
  • price（$） 1.809
Single Row Deep Groove Ball Bearings 609-2Z/C3LHT23 dimension drawing
Download DWG Download PDF

Features

Performance Features of 609-2Z/C3LHT23 Bearing

609-2Z/C3LHT23 Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 642 lbf ensures steady performance in various applications.

The shielded design protects against dust and debris, enhancing durability.
With a maximum speed of 32,000 rpm, it delivers smooth operation for high-speed needs.

Its C3 radial clearance allows for thermal expansion, making it suitable for varied temperatures.
The compact size of 9 mm×24 mm×7 mm makes it ideal for space-constrained installations.

Application

Common Applications of 609-2Z/C3LHT23 Bearing
In industrial settings, 609-2Z/C3LHT23 Bearing is commonly used in small electric motors and pumps due to its shielded design, which helps keep contaminants out. Its C3 clearance allows for slight thermal expansion, making it suitable for variable-speed applications.

Where Is 609-2Z/C3LHT23 Bearing Used?
You’ll often find 609-2Z/C3LHT23 Bearing in household appliances like washing machines and fans, where its compact size and reliable performance are key. The chrome steel construction ensures it handles everyday wear with ease.

Ideal for Precision: 609-2Z/C3LHT23 Bearing
For automation equipment, 609-2Z/C3LHT23 Bearing offers smooth operation in robotic arms and small conveyors. Its ABEC 1 tolerance provides consistent performance without overcomplicating the design.

Automotive vs Industrial: Applications of 609-2Z/C3LHT23 Bearing
In automotive applications, 609-2Z/C3LHT23 Bearing fits well in auxiliary components like alternators and small gearboxes. Meanwhile, its industrial uses extend to light machinery where radial load support is needed.

Practical Applications of 609-2Z/C3LHT23 Bearing
Medical devices like dental handpieces benefit from 609-2Z/C3LHT23 Bearing’s quiet operation and durability. The shielded design also helps maintain hygiene by reducing dust ingress.
