Single Row Cylindrical Roller Thrust Bearings 81116 TN

Single Row Cylindrical Roller Thrust Bearings 81116 TN

The 81116 TN is a single-row cylindrical roller thrust bearing, measuring 80mm by 105mm by 19mm. Made from chrome steel, it’s built to handle heavy thrust loads with ease.

It supports dynamic radial loads up to 18338 lbf and can run smoothly at speeds up to 3000 RPM. The glass fibre reinforced PA66 cage adds durability while keeping the weight light at just 0.4kg.

Its design includes a shaft washer and housing washer for secure fitting. The bearing operates well in temperatures from -30°C to 110°C, making it versatile for various conditions.

Ideal for industrial machinery or heavy equipment where high thrust loads are common. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, especially as it’s interchangeable with SKF bearings.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 81116 TN
  • size 80 mm x 105 mm x 19 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 1
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 105 mm
  • Outer Dia Tolerance -0.022mm to 0
  • Width 19 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 105 mm
  • Bore Diameter Housing Washer 82 mm
  • Height Shaft Washer 5.75 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 1 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 18338 lbf
  • Static Radial Load 75375 lbf
  • Max Speed 3000 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.4 kg
  • Roller And Cage Thrust Assembly K 81116 TN
  • Shaft Washer WS 81116
  • Housing Washer GS 81116
Single Row Cylindrical Roller Thrust Bearings 81116 TN dimension drawing
Download DWG Download PDF

Features

Performance Features of 81116 TN Bearing

81116 TN Bearing is built with chrome steel washers and rollers, offering strong resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 18338 lbf, ensuring reliable performance in demanding applications.

The glass fibre reinforced PA66 cage keeps the rollers aligned, reducing wear and extending service life.
With a maximum speed of 3000 rpm, it balances durability and efficiency in high-load scenarios.

81116 TN Bearing operates smoothly in temperatures ranging from -30° to 110°C, making it versatile for various environments.
Its precise dimensions and tolerances ensure easy installation and consistent performance.

The interchangeable design with SKF bearings provides flexibility and convenience for users.
Its robust construction and material composition make it a dependable choice for industrial applications.

Application

Where Is 81116 TN Bearing Used?
81116 TN Bearing is commonly used in industrial machinery for handling heavy axial loads, such as in hydraulic presses and large gearboxes. Its cylindrical roller design ensures stability and efficiency under high-pressure conditions.

In automotive applications, 81116 TN Bearing supports components like clutch release mechanisms and steering systems. The chrome steel construction provides durability, while the glass fibre reinforced cage offers resistance to wear and heat.

For automation systems, 81116 TN Bearing is ideal for robotic arms and conveyor belts, where precision and reliability are key. The metric sizing makes it compatible with a variety of European and Asian equipment standards.

In medical devices, 81116 TN Bearing’s high load capacity and smooth operation make it suitable for imaging equipment and surgical tools. The temperature range ensures consistent performance in various clinical environments.
