560 Single Cones (Imperial)

560 Single Cones (Imperial)

The 560 single cones are tapered roller bearings with a 2.625-inch bore, designed for combined loads. Made from chrome steel, they handle dynamic radial loads up to 50,800 lbf and static loads up to 55,700 lbf.

Their single-row construction and open design allow for easy maintenance, while the steel cage ensures durability. The bearings operate smoothly in temperatures from -30°C to 110°C.

Interchangeable with Timken models, these cones are ideal for heavy-duty applications like truck axles or industrial gearboxes. They come with standard radial clearance, but options like C3/C4/C5 are available.

Compliant with RoHS and REACH standards, these bearings offer reliable performance in demanding conditions. Their tapered design provides stability under both radial and thrust loads.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 560
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Inch
  • Type Cones
  • Bearing Part Number 560-552 , 560-552A , 560-552AX , 560-553-SA , 560-553A , 560-553X , 560-S-552 , 560-S-552-S , 560-S-552A , 560-552-B , 560-S-552-B
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Series 555
  • Bore Dia 2.625"
  • Bore Dia Tolerance +0.005" to 0
  • Cone Width 1.444"
  • Cone Width Tolerance +0.003" to -0.01
  • Cone Backface ToClear Radius 0.14"
  • Cone Frontface Backing Diameter 3.03"
  • Cone Backface Backing Diameter 3.31"
  • Cage Cone Frontface Clearance 0.08"
  • Cage Cone Backface Clearance 0.07"
  • Effective Center Location -0.37"
  • Ring Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 50800 lbf
  • Static Radial Load 55700 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 13200 lbf
  • Dynamic Radial Rating(Two Row 1 Million Revolutions)(C1) 88500 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 7810 lbf
  • Dynamic Radial Rating(Two Row 90 Million Revolutions)(C90) 22900 lbf
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant

Features

Performance Features of 560 Single Cones (Imperial)

560 Single Cones (Imperial) are crafted from chrome steel, offering robust resistance to combined loads.
Their dynamic radial load capacity reaches 50,800 lbf, ensuring reliable performance in demanding conditions.

The steel cage maintains roller alignment, reducing wear and extending operational life.
With a temperature range of -30° to 110°C, they perform well in various environments.

Designed for easy interchangeability with Timken models, they simplify maintenance and replacement.
The standard radial clearance option provides flexibility for different applications.

Application

Industrial Uses of 560 Single Cones
560 Single Cones are commonly used in heavy machinery like construction equipment and agricultural gear, where their tapered roller design handles combined loads effectively. The open seal allows for easy lubrication, which is handy in dusty environments.

In automotive applications, 560 Single Cones support wheel hubs and differential systems, providing reliable performance under varying loads. Their inch sizing makes them a straightforward fit for many American and British vehicle models.

For industrial conveyors, 560 Single Cones offer durability and smooth operation, even under continuous use. The chrome steel construction ensures long-lasting performance in demanding settings.

What Makes 560 Single Cones a Preferred Choice?
560 Single Cones are often chosen for their ability to manage both radial and thrust loads in machinery like gearboxes and pumps. The steel cage adds strength, making them suitable for high-stress applications.

Their standard radial clearance options provide flexibility for different operational needs, from light to heavy-duty scenarios. This versatility makes them a practical pick for various industrial setups.

Built for Heavy-Duty Use: 560 Single Cones
560 Single Cones excel in mining equipment, where their robust design withstands extreme conditions. The tapered rollers distribute loads evenly, reducing wear over time.

In forestry machinery, these cones handle the rough terrain and heavy loads typical of the industry. Their temperature range ensures reliable performance in both hot and cold environments.

Automotive vs Aerospace: Applications of 560 Single Cones
In automotive systems, 560 Single Cones are trusted for their durability in wheel bearings and transmissions. Their inch measurements simplify replacements in older vehicle models.

For aerospace ground equipment, these cones provide precision and reliability in load-handling components. While not used in-flight, they’re vital for maintenance and support machinery.
