22324 CCK/C2W33 Double Row Spherical Roller Bearing

22324 CCK/C2W33 Double Row Spherical Roller Bearing

The 22324 CCK/C2W33 is a double-row spherical roller bearing with a 120mm bore and 260mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 22908 lbf and runs smoothly at speeds up to 3900 RPM.

Its open design and tapered bore ensure easy installation, while the steel cage provides reliable performance. The bearing operates well in temperatures from -30°C to 200°C, making it suitable for demanding environments.

This model is interchangeable with SKF bearings, offering a practical replacement option. Ideal for heavy machinery or industrial equipment where combined loads and high speeds are common.

Weighing 22.5kg, it’s built for durability and long service life. Compliant with RoHS and REACH standards, it’s a safe choice for various applications.

The lubrication groove and holes simplify maintenance, ensuring consistent performance. Its spherical roller design accommodates misalignment, reducing wear and tear.

Perfect for use in mining, construction, or manufacturing sectors where robust bearings are essential. The C2 radial clearance provides optimal performance under varying load conditions.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22324 CCK/C2W33
  • Brand TFL
  • Interchangeable SKF
  • Size 120 x 260 x 86 mm
  • Bore Dia 120 mm
  • Bore Dia Tolerance +0.035mm to 0
  • Outer Dia 260 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 86 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 152 mm
  • Shoulder/Recess Dia Of Outer Ring 216 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 22908 lbf
  • Static Radial Load 251786 lbf
  • Max Speed 3900 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 22.5 kg
  • Price （US$） US$325.04

Features

Performance Features of 22324 CCK/C2W33 Bearing

22324 CCK/C2W33 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22908 lbf, ensuring reliable operation in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
With a maximum speed of 3900 rpm, it maintains performance under high-speed conditions.

22324 CCK/C2W33 Bearing operates in temperatures from -30° to 200°C, suitable for various environments.
The steel cage ensures roller alignment, enhancing durability and reducing maintenance needs.

The lubrication groove and hole design in 22324 CCK/C2W33 Bearing facilitate easy maintenance.
Its C2 radial clearance provides optimal performance for precision applications.

Application

Industrial Uses of 22324 CCK/C2W33 Bearing
This bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction helps accommodate misalignment, reducing wear in demanding environments.

Where Is 22324 CCK/C2W33 Bearing Used?
You’ll often find it in mining equipment, where its high dynamic load capacity ensures reliable performance under extreme conditions. The tapered bore also simplifies installation in large shafts, saving time during maintenance.

Built for Heavy-Duty Use: 22324 CCK/C2W33 Bearing
In paper mills, this bearing supports large rollers, withstanding high speeds and heavy loads. The steel cage and chrome steel rollers provide durability, even in humid or dusty settings.

Automotive vs Aerospace: Applications of 22324 CCK/C2W33 Bearing
While it’s too large for most aerospace uses, this bearing excels in heavy vehicles like lorries and buses. Its combined load capacity makes it ideal for wheel hubs and transmission systems.

Key Fields for 22324 CCK/C2W33 Bearing
Wind turbines benefit from its ability to handle fluctuating loads and misalignment. The C2 radial clearance ensures smooth rotation, even under varying temperatures and speeds.
