TS (Single Row Tapered Roller Bearings) (Imperial) 25572-25526

TS (Single Row Tapered Roller Bearings) (Imperial) 25572-25526

The 25572-25526 is a single-row tapered roller bearing with a 1.5″ bore and 3.3465″ outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 20300 lbf radially and 3020 lbf in thrust, suitable for moderate-speed applications.

Its open design allows for easy lubrication, while the steel cage ensures durability under stress. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for use in automotive or industrial equipment where combined loads are common.

Weighing 1.5 lb, it offers a balance of strength and manageable size. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 25572-25526
  • Brand TFL
  • Interchangeable Timken
  • Size 1.5" x 3.3465" x 0.9375"
  • Bore Dia 1.5"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 3.3465"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.75"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 0.9375"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.03"
  • Cup Backface ToClear Radius 0.090"
  • Cone Frontface Backing Diameter 1.81"
  • Cone Backface Backing Diameter 1.81"
  • Cup Frontface Backing Diameter 3.11"
  • Cup Backface Backing Diameter 2.91"
  • Cage Cone Frontface Clearance 0.06"
  • Cage Cone Backface Clearance 0.01"
  • Effective Center Location -0.25"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 25572
  • Cup Part Number 25526
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 25500
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 20300 lbf
  • Static Radial Load 24900 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 5270 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 3020 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.500 lb

Features

How Does 25572-25526 Bearing Handle Combined Loads?

25572-25526 Bearing is built with chrome steel rings and rollers, offering strong resistance to both radial and thrust loads.
Its dynamic radial load capacity reaches 20,300 lbf, ensuring reliable performance in demanding conditions.
The steel cage maintains roller alignment, reducing friction and extending service life.
With a temperature range of -30° to 110°C, it performs well in various environments.

Why Choose 25572-25526 Bearing for Precision Tasks?

25572-25526 Bearing features a single-row tapered roller design, providing precise load distribution.
The chrome steel construction enhances durability while maintaining smooth operation.
Its standard radial clearance ensures consistent performance in precision applications.
The bearing’s ABEC-1 rating confirms its suitability for tasks requiring reliable accuracy.

Engineered for Reliability: 25572-25526 Bearing

25572-25526 Bearing’s tapered roller design efficiently manages combined loads with minimal friction.
The chrome steel components resist wear, ensuring long-term performance even under heavy stress.
Its dynamic thrust rating of 3,020 lbf highlights its capability in demanding applications.
The open seal type allows for easy lubrication, further enhancing its reliability.

Application

Industrial Uses of 25572-25526 Bearing
25572-25526 Bearing is commonly used in heavy machinery, such as construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability even in demanding environments.

What Makes 25572-25526 Bearing a Preferred Choice?
In automotive applications, 25572-25526 Bearing fits well in wheel hubs and differential systems, thanks to its precise inch sizing and robust load capacity. Its open design simplifies lubrication, extending service life.

Built for Heavy-Duty Use: 25572-25526 Bearing
For industrial conveyor systems, 25572-25526 Bearing offers reliable performance under continuous radial and thrust loads. The steel cage provides added strength, making it suitable for high-stress operations.

Automotive vs Aerospace: Applications of 25572-25526 Bearing
In automotive settings, 25572-25526 Bearing supports drivetrain components, while its aerospace applications are limited due to weight constraints. Its ABEC-1 rating ensures consistent performance in general machinery.

Essential Roles of 25572-25526 Bearing
25572-25526 Bearing is ideal for mining equipment, where its tapered rollers manage heavy radial and axial loads. The standard radial clearance allows for smooth operation in varied temperature conditions.
