TS (Single Row Tapered Roller Bearings) (Imperial) 09081-09196

TS (Single Row Tapered Roller Bearings) (Imperial) 09081-09196

The 09081-09196 is a single-row tapered roller bearing with a 0.812″ bore and 1.938″ outer diameter, crafted from durable chrome steel. It handles combined loads up to 9630 lbf radially and 1140 lbf thrust, making it versatile for various applications.

Its open design allows easy lubrication, while the steel cage ensures reliable performance. The bearing operates smoothly in temperatures from -30°C to 110°C, suitable for demanding environments.

This model is interchangeable with Timken bearings, offering a practical replacement option. Ideal for gearboxes, axles, or industrial machinery where combined loads are common.

Weighing just 0.4 lb, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 09081-09196
  • Brand TFL
  • Interchangeable Timken
  • Size 0.812" x 1.938" x 0.9063"
  • Bore Dia 0.812"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 1.938"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 0.848"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.6875"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 0.9063"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.06"
  • Cup Backface ToClear Radius 0.06"
  • Cone Frontface Backing Diameter 1"
  • Cone Backface Backing Diameter 1.08"
  • Cup Frontface Backing Diameter 1.79"
  • Cup Backface Backing Diameter 1.63"
  • Cage Cone Frontface Clearance 0.06"
  • Cage Cone Backface Clearance 0.07"
  • Effective Center Location -0.36"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 9081
  • Cup Part Number 9196
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 9000
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 9630 lbf
  • Static Radial Load 9100 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 2500 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 1140 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.4 lb

Features

Performance Features of 09081-09196 Bearing

09081-09196 Bearing is crafted with chrome steel rings and rollers, offering robust performance under combined loads.
Its dynamic radial load capacity reaches 9630 lbf, making it suitable for demanding industrial applications.
The steel cage maintains roller alignment, ensuring smooth operation and extended service life.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

How Is 09081-09196 Bearing Engineered for Reliability?

09081-09196 Bearing features a single-row tapered roller design, optimised for handling both radial and thrust loads.
The chrome steel construction enhances durability, while the standard radial clearance allows for versatile use.
Its effective center location of -0.36″ ensures precise alignment in machinery.
This bearing meets ABEC-1 standards, balancing performance and affordability.

Built for Durability: 09081-09196 Bearing

09081-09196 Bearing’s tapered rollers and chrome steel components provide excellent resistance to wear.
The dynamic thrust rating of 1140 lbf ensures reliable performance under heavy loads.
Its open design simplifies lubrication, reducing maintenance requirements.
With a weight of just 0.4 lb, it offers a lightweight yet sturdy solution for various applications.

Steel vs Ceramic Bearings: Strengths of 09081-09196 Bearing

09081-09196 Bearing uses chrome steel for both rollers and rings, ensuring cost-effective durability.
The standard radial clearance and ABEC-1 rating make it versatile for different precision needs.
Its tapered roller design efficiently handles combined loads, outperforming many alternatives.
The bearing’s compliance with RoHS and REACH standards highlights its environmental safety.

Application

Key Fields for 09081-09196 Bearing
In industrial settings, 09081-09196 Bearing is commonly used in conveyor systems and gearboxes, where its tapered roller design handles combined loads efficiently. The chrome steel construction ensures durability even in demanding environments.

Where Is 09081-09196 Bearing Used?
You’ll often find 09081-09196 Bearing in automotive applications like wheel hubs and differentials, thanks to its ability to manage both radial and thrust loads. Its inch sizing makes it a fit for many North American vehicle models.

Built for Heavy-Duty Use: 09081-09196 Bearing
09081-09196 Bearing excels in construction equipment, such as bulldozers and cranes, where its robust design withstands heavy loads. The steel cage adds extra strength, making it reliable for long-term use.

Automotive vs Aerospace: Applications of 09081-09196 Bearing
In automotive systems, 09081-09196 Bearing supports high-stress components like axles. While not typically used in aerospace, its precision and load capacity make it suitable for similar high-performance machinery.

Perfect Fit for Automation: 09081-09196 Bearing
09081-09196 Bearing works well in automated machinery, such as robotic arms, where smooth rotation is key. Its standard radial clearance ensures consistent performance in repetitive tasks.
