TS (Single Row Tapered Roller Bearings) (Imperial) 02476-02420A

TS (Single Row Tapered Roller Bearings) (Imperial) 02476-02420A

The 02476-02420A is a single-row tapered roller bearing with a 1.25″ bore and 2.6875″ outer diameter, crafted from durable chrome steel. It handles combined loads up to 14300 lbf radially and 2650 lbf thrust, suitable for demanding applications.

Its open design allows easy lubrication, while the steel cage ensures reliable performance. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for use in gearboxes, axles, or industrial machinery where combined loads are common.

Weighing just 0.8 lb, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 02476-02420A
  • Brand TFL
  • Interchangeable Timken
  • Size 1.25" x 2.6875" x 0.8268"
  • Bore Dia 1.25"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 2.6875"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 0.875"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.6393"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 0.8268"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.03"
  • Cup Backface ToClear Radius 0.06"
  • Cone Frontface Backing Diameter 1.52"
  • Cone Backface Backing Diameter 1.54"
  • Cup Frontface Backing Diameter 2.52"
  • Cup Backface Backing Diameter 2.32"
  • Cage Cone Frontface Clearance 0.06"
  • Cage Cone Backface Clearance 0.03"
  • Effective Center Location -0.2"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 2476
  • Cup Part Number 02420A
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 2400
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 14300 lbf
  • Static Radial Load 15800 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 3720 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 2650 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.8 lb

Features

Performance Features of 02476-02420A Bearing

02476-02420A Bearing is crafted with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 14,300 lbf, ensuring reliable performance in various applications.
The steel cage maintains proper roller alignment, reducing friction and extending service life.
With a temperature range of -30° to 110°C, it performs well in diverse operating conditions.

How Is 02476-02420A Bearing Engineered for Reliability?

02476-02420A Bearing features a single-row tapered roller design, optimised for handling both radial and thrust loads.
The chrome steel construction provides durability, while the standard radial clearance ensures smooth operation.
Its effective centre location of -0.2″ enhances stability during rotation.
With an ABEC-1 rating, it balances precision and cost-effectiveness for industrial use.

Built for Durability: 02476-02420A Bearing

02476-02420A Bearing’s tapered roller design distributes loads evenly, reducing stress on components.
The steel cage and chrome steel rollers work together to minimise wear over time.
It withstands static radial loads up to 15,800 lbf, making it suitable for heavy-duty applications.
Regular lubrication ensures consistent performance throughout its service life.

Application

Industrial Uses of 02476-02420A Bearing
02476-02420A Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined radial and thrust loads effectively. The chrome steel construction ensures durability in demanding environments.

Where Is 02476-02420A Bearing Used?
You’ll often find 02476-02420A Bearing in automotive applications, particularly in wheel hubs and transmissions. Its inch sizing makes it a convenient choice for American-made vehicles and machinery.

Built for Heavy-Duty Use: 02476-02420A Bearing
02476-02420A Bearing performs well in agricultural machinery, supporting components that face constant vibration and shock loads. The steel cage provides reliable performance in these tough conditions.

Automotive vs Aerospace: Applications of 02476-02420A Bearing
While 02476-02420A Bearing is popular in truck wheel assemblies, it’s also suitable for some aerospace ground support equipment. The standard radial clearance offers flexibility for different operational needs.

Key Fields for 02476-02420A Bearing
02476-02420A Bearing works efficiently in industrial gearboxes, where its ABEC-1 rating provides adequate precision for most applications. The temperature range suits typical factory environments.
