Thin Section Ball Bearings SER1038 ZZ

Thin Section Ball Bearings SER1038 ZZ

The SER1038 ZZ is a slim, shielded ball bearing measuring 0.375″ by 0.625″ by 0.1562″, crafted entirely from stainless steel for corrosion resistance. It supports radial loads up to 193 lbf and spins efficiently at speeds up to 15,000 RPM.

Its shielded design keeps contaminants out while maintaining smooth operation, and the ABEC-1 tolerance ensures reliable performance. The bearing requires lubrication for optimal use and works in temperatures from -86°F to 230°F.

Weighing just 2.6g, it’s ideal for compact applications like small motors or precision instruments where space is limited. Compliant with RoHS and REACH standards, it’s a practical choice for lightweight, durable radial load solutions.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SER1038 ZZ
  • Brand TFL
  • Bore Dia 0.375"
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 0.625"
  • Outer Dia Tolerance -0.008mm to 0
  • Width 0.1562"
  • Width Tolerance -0.12mm to 0
  • Radial Clearance 0.003mm to 0.018mm
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 193 lbf
  • Static Radial Load 98 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Weight 2.6 g
  • Price（$） 2
Thin Section Ball Bearings SER1038 ZZ dimension drawing
Download DWG Download PDF

Features

Performance Features of SER1038 ZZ Bearing

SER1038 ZZ Bearing is crafted with stainless steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 193 lbf ensures steady performance in various applications.

The shielded design protects against contaminants while maintaining smooth operation.
With a maximum speed of 15,000 rpm, it balances efficiency and durability.

SER1038 ZZ Bearing operates in temperatures from -86 to 230 °F, suitable for diverse environments.
Its compact size and lightweight design make it ideal for space-constrained applications.

Application

Common Applications of SER1038 ZZ Bearing
SER1038 ZZ Bearing works well in industrial equipment like small conveyor systems, where its thin section design saves space without compromising performance. The shielded seals help keep contaminants out, extending its lifespan in dusty environments.

In robotics, SER1038 ZZ Bearing is often used in joint assemblies due to its smooth rotation and lightweight stainless steel construction. Its ABEC-1 tolerance ensures reliable movement for precise tasks like pick-and-place operations.

For consumer electronics, SER1038 ZZ Bearing fits neatly into devices like printers or small fans, where compact size matters. The stainless steel materials resist corrosion, making it suitable for humid or high-temperature conditions.

Medical devices like handheld diagnostic tools benefit from SER1038 ZZ Bearing’s quiet operation and consistent radial load handling. The shielded design also prevents lubricant leakage, maintaining cleanliness in sensitive environments.
