Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64F

Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64F

The W 6305-2RS1/W64F is a stainless steel deep groove ball bearing with a 25mm bore and 62mm outer diameter, designed for radial loads. It handles dynamic loads up to 4002 lbf and spins smoothly at speeds up to 17000 RPM.

Sealed on both sides, it keeps dirt out and retains lubrication, making it low-maintenance. The stainless steel construction resists corrosion, ideal for humid or wet environments.

With a solid oil lubricant, it performs well in temperatures from -30°C to 120°C. This model is interchangeable with SKF bearings, offering a reliable replacement option.

Suitable for applications like electric motors or food processing equipment where hygiene and durability are key. Weighing 0.22kg, it’s a sturdy yet lightweight choice. Compliant with REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6305-2RS1/W64F
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 4002 lbf
  • Static Radial Load 2518 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 17000 rpm
  • Weight 0.22 kg
  • Price（$） 47.39
Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64F dimension drawing
Download DWG Download PDF

Features

Why Choose W 6305-2RS1/W64F Bearing for Precision Tasks?

W 6305-2RS1/W64F Bearing features stainless steel rings and balls, ensuring corrosion resistance and durability.
Its sealed design keeps out contaminants, making it ideal for environments with dust or moisture.

The solid oil lubrication reduces maintenance needs while providing consistent performance.
With a maximum speed of 17,000 rpm, it delivers smooth operation in high-speed applications.

W 6305-2RS1/W64F Bearing’s ABEC 1 tolerance ensures reliable precision for radial load tasks.
Its dynamic radial load capacity of 4002 lbf makes it suitable for demanding industrial uses.

Application

Industrial Uses of W 6305-2RS1/W64F Bearing
W 6305-2RS1/W64F Bearing is commonly used in industrial settings, such as pumps and compressors, where its sealed design helps keep contaminants out. The stainless steel construction also makes it suitable for environments where corrosion resistance is important.

What Makes W 6305-2RS1/W64F Bearing a Preferred Choice?
In automotive applications, W 6305-2RS1/W64F Bearing works well in electric motors and wheel hubs due to its solid oil lubrication and radial load capacity. Its metric sizing ensures easy integration with various vehicle designs.

Perfect Fit for Automation: W 6305-2RS1/W64F Bearing
For automated systems like conveyor belts, W 6305-2RS1/W64F Bearing offers reliable performance with minimal maintenance. The ABEC 1 tolerance ensures smooth operation in precision-driven tasks.

Medical vs Industrial: Where W 6305-2RS1/W64F Bearing Excels
In medical devices, W 6305-2RS1/W64F Bearing provides quiet and consistent operation, ideal for imaging equipment. Its stainless steel balls and rings also meet hygiene standards in sensitive environments.
