Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64

Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64

The W 6305-2RS1/W64 is a stainless steel deep groove ball bearing with a 25mm bore and 62mm outer diameter, measuring 17mm wide. Its sealed design keeps dirt out and retains lubrication, making it low-maintenance.

This bearing handles radial loads up to 4002 lbf and spins smoothly at speeds up to 17000 RPM. The stainless steel construction resists corrosion, while the chrome steel cage adds durability.

It operates in temperatures from -30°C to 120°C and comes pre-lubricated with solid oil for long service life. Ideal for food processing or marine applications where rust resistance is key.

Weighing 0.22kg, it’s a sturdy yet lightweight option. Compliant with REACH standards and interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6305-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 4002 lbf
  • Static Radial Load 2518 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 17000 rpm
  • Weight 0.22 kg
  • Price（$） 43.34
Stainless Steel Deep Groove Ball Bearings W 6305-2RS1/W64 dimension drawing
Download DWG Download PDF

Features

Why Choose W 6305-2RS1/W64 Bearing for Precision Tasks?

W 6305-2RS1/W64 Bearing features stainless steel rings and balls, offering excellent corrosion resistance and durability.
Its sealed design keeps contaminants out, ensuring smooth operation in various environments.

The dynamic radial load capacity of 4002 lbf makes it suitable for demanding applications.
With a maximum speed of 17,000 rpm, it delivers reliable performance without compromising efficiency.

Solid oil lubrication reduces maintenance needs, extending the bearing’s service life.
The ABEC 1 tolerance ensures consistent precision, ideal for radial load applications.

Application

Industrial Uses of W 6305-2RS1/W64 Bearing
W 6305-2RS1/W64 Bearing is commonly used in industrial machinery, such as pumps and compressors, where its sealed design helps keep contaminants out. The stainless steel construction also makes it suitable for environments where corrosion resistance is important.

How Does W 6305-2RS1/W64 Bearing Improve Performance?
In automotive applications, W 6305-2RS1/W64 Bearing enhances performance in electric motors and gearboxes due to its reliable radial load handling. The solid oil lubrication ensures smooth operation even at higher speeds.

Perfect Fit for Automation: W 6305-2RS1/W64 Bearing
W 6305-2RS1/W64 Bearing works well in robotic arms and conveyor systems, where its consistent performance reduces downtime. The metric sizing makes it easy to integrate into various automated setups.

Medical vs Industrial: Where W 6305-2RS1/W64 Bearing Excels
W 6305-2RS1/W64 Bearing is a good choice for medical devices like lab equipment, thanks to its stainless steel components. In industrial settings, it handles heavy loads in machinery like food processing units.

Where to Use W 6305-2RS1/W64 Bearing
For household appliances like washing machines, W 6305-2RS1/W64 Bearing provides quiet and efficient operation. Its sealed design also helps extend the bearing’s lifespan in dusty or humid conditions.
