Stainless Steel Deep Groove Ball Bearings W 627/6 X

Stainless Steel Deep Groove Ball Bearings W 627/6 X

The W 627/6 X is a compact stainless steel deep groove ball bearing, measuring 6mm in bore and 12mm in outer diameter, with a slim 3mm width. Its all-stainless construction ensures good corrosion resistance and durability.

This bearing handles radial loads up to 91 lbf and can spin at speeds up to 70,000 RPM, making it suitable for high-speed applications. The open design allows for easy lubrication when needed.

With a P0 tolerance class and CN radial clearance, it offers reliable performance in precision equipment. The lightweight design (just 0.0012kg) doesn’t compromise strength.

Ideal for small machinery, medical devices, or food processing equipment where corrosion resistance matters. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 627/6 X
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 12 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 3 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 91 lbf
  • Static Radial Load 33 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 70000 rpm
  • Weight 0.0012 kg
Stainless Steel Deep Groove Ball Bearings W 627/6 X dimension drawing
Download DWG Download PDF

Features

Why Choose W 627/6 X Bearing for Precision Tasks?

W 627/6 X Bearing is crafted from stainless steel, offering excellent corrosion resistance and durability.
Its compact size of 6 mm×12 mm×3 mm makes it ideal for applications where space is limited.
With a dynamic radial load capacity of 91 lbf, it handles light to moderate loads efficiently.
The bearing’s high-speed capability of 70,000 rpm ensures smooth operation in precision instruments.

Application

Key Fields for W 627/6 X Bearing
W 627/6 X Bearing is commonly used in small industrial equipment, such as miniature motors and precision instruments, where its compact size and stainless steel construction are ideal. The open design ensures easy access for lubrication, extending its service life in demanding conditions.

In automotive applications, W 627/6 X Bearing fits well in components like electric window mechanisms or fuel pumps, thanks to its radial load capacity. Its metric dimensions make it a versatile choice for various vehicle models.

For medical devices, W 627/6 X Bearing’s stainless steel build offers reliability in equipment like dental tools or lab instruments. The high-speed capability ensures smooth operation in critical settings.

Automation and robotics benefit from W 627/6 X Bearing’s precision, particularly in small robotic arms or 3D printers. Its lightweight design reduces overall system load while maintaining performance.

In consumer electronics, W 627/6 X Bearing is found in devices like cooling fans or small appliances, where quiet and efficient operation is key. The corrosion-resistant materials make it suitable for long-term use.
