Stainless Steel Deep Groove Ball Bearings W 626-2RS1/VT378

Stainless Steel Deep Groove Ball Bearings W 626-2RS1/VT378

The W 626-2RS1/VT378 is a compact stainless steel deep groove ball bearing, measuring 6mm by 19mm by 6mm. It handles radial loads up to 344 lbf and spins smoothly at speeds up to 56,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The stainless steel construction offers good corrosion resistance for damp or washdown environments.

This bearing is interchangeable with SKF models, ideal for replacements in small machinery or appliances. It works in temperatures from -30°C to 120°C.

Weighing just 7.1 grams, it’s a lightweight choice for applications where space is tight. Compliant with REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 626-2RS1/VT378
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 344 lbf
  • Static Radial Load 132 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 56000 rpm
  • Weight 0.0071 kg
Stainless Steel Deep Groove Ball Bearings W 626-2RS1/VT378 dimension drawing
Download DWG Download PDF

Features

Why Choose W 626-2RS1/VT378 Bearing for Precision Tasks?

W 626-2RS1/VT378 Bearing is crafted with stainless steel rings and balls, ensuring corrosion resistance and durability.
Its sealed design protects against dust and moisture, making it suitable for various environments.

The bearing handles dynamic radial loads up to 344 lbf, providing reliable performance in precision applications.
With a maximum speed of 56,000 rpm, it balances efficiency and smooth operation.

W 626-2RS1/VT378 Bearing’s compact size (6 mm×19 mm×6 mm) makes it ideal for space-constrained installations.
Its chrome steel cage ensures proper ball alignment, reducing wear and extending service life.

Application

Practical Applications of W 626-2RS1/VT378 Bearing
W 626-2RS1/VT378 Bearing is commonly used in small electric motors, such as those found in household appliances like fans and blenders. Its sealed design helps keep out dust and moisture, ensuring long-lasting performance in everyday use.

In automation systems, W 626-2RS1/VT378 Bearing fits well in compact robotic arms and precision-guided mechanisms. The stainless steel construction offers good resistance to corrosion, making it suitable for environments where cleanliness is important.

For medical devices, W 626-2RS1/VT378 Bearing provides smooth operation in handheld instruments and diagnostic equipment. The ABEC 1 tolerance ensures reliable performance without unnecessary complexity or cost.

Consumer electronics like printers and small gadgets benefit from W 626-2RS1/VT378 Bearing’s quiet and efficient rotation. The lightweight design and metric sizing make it easy to integrate into various compact devices.
