Stainless Steel Deep Groove Ball Bearings W 6010-2RS1/W64

Stainless Steel Deep Groove Ball Bearings W 6010-2RS1/W64

The W 6010-2RS1/W64 is a stainless steel deep groove ball bearing with a 50mm bore and 80mm outer diameter, measuring 16mm wide. Its sealed design keeps dirt out and solid oil lubrication ensures smooth operation.

This bearing handles radial loads up to 4271 lbf and can spin at speeds up to 11000 RPM. Made entirely from stainless steel (except the chrome steel cage), it resists corrosion and lasts longer in harsh conditions.

The sealed construction makes it low-maintenance, ideal for wet or dusty environments. It works in temperatures from -30°C to 120°C, suitable for food processing or marine applications.

Weighing 0.24kg, it’s a sturdy yet manageable size. Compliant with REACH standards, it’s interchangeable with SKF bearings for easy replacement in machinery or industrial equipment.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6010-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 4271 lbf
  • Static Radial Load 3732 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.24 kg
Stainless Steel Deep Groove Ball Bearings W 6010-2RS1/W64 dimension drawing
Download DWG Download PDF

Features

Why Choose W 6010-2RS1/W64 Bearing for Precision Tasks?

W 6010-2RS1/W64 Bearing features stainless steel rings and balls, ensuring excellent corrosion resistance and durability.
Its sealed design with solid oil lubrication keeps contaminants out, reducing maintenance needs.

The bearing handles dynamic radial loads up to 4271 lbf, making it suitable for demanding applications.
With a maximum speed of 11,000 rpm, it delivers reliable performance in high-speed operations.

W 6010-2RS1/W64 Bearing operates in temperatures from -30°C to 120°C, adapting to various environments.
Its precision construction meets ABEC 1 and ISO P0 standards, ensuring consistent performance.

Application

Industrial Uses of W 6010-2RS1/W64 Bearing
W 6010-2RS1/W64 Bearing is commonly used in industrial settings, such as conveyor systems and pumps, where its sealed design helps keep contaminants out. The stainless steel construction also makes it suitable for environments where corrosion resistance is important.

How Does W 6010-2RS1/W64 Bearing Improve Performance?
In automotive applications like electric motors, W 6010-2RS1/W64 Bearing provides reliable radial load support with minimal maintenance. Its solid oil lubrication ensures smooth operation even at higher speeds.

Perfect Fit for Automation: W 6010-2RS1/W64 Bearing
W 6010-2RS1/W64 Bearing works well in robotic arms and automated machinery, thanks to its consistent performance and durability. The ABEC 1 tolerance ensures it meets precision requirements for these applications.

Medical vs Industrial: Where W 6010-2RS1/W64 Bearing Excels
W 6010-2RS1/W64 Bearing is a good choice for medical devices like lab equipment, where hygiene and reliability are key. In industrial settings, it handles heavy loads in machinery like compressors with ease.

Where to Use W 6010-2RS1/W64 Bearing
For household appliances like washing machines, W 6010-2RS1/W64 Bearing offers quiet and efficient operation. Its sealed design also helps extend the bearing’s life in dusty or humid conditions.
