Snap Ring Groove Ball Bearings 6201-2RSNR/C3

Snap Ring Groove Ball Bearings 6201-2RSNR/C3

The 6201-2RSNR/C3 is a compact sealed ball bearing with a 12mm bore and 32mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 1529 lbf and spins smoothly at speeds up to 22,000 RPM.
Its snap ring groove ensures secure fitting, while the sealed design keeps out dust and moisture for longer life. The bearing performs reliably in temperatures from -30°C to 120°C.
This model is interchangeable with SKF bearings, making replacements straightforward. Ideal for small machinery, electric motors, or appliances where space is limited.
Weighing just 37g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6201-2RSNR/C3
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 10 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 34.7 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1529 lbf
  • Static Radial Load 686 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 22000 rpm
  • Weight 37 g
  • Price（$） 2.12
Snap Ring Groove Ball Bearings 6201-2RSNR/C3 dimension drawing
Download DWG Download PDF

Features

How Does 6201-2RSNR/C3 Bearing Reduce Friction?

6201-2RSNR/C3 Bearing features a sealed design with chrome steel components, ensuring smooth operation and reduced friction.

The snap ring groove on the outer ring provides secure positioning, enhancing stability during high-speed rotations.

With a dynamic radial load capacity of 1529 lbf, it handles demanding applications efficiently.

Its temperature range of -30° to 120°C makes it suitable for various operating conditions.

Application

Common Applications of 6201-2RSNR/C3 Bearing
6201-2RSNR/C3 Bearing is widely used in industrial equipment like conveyor systems and small electric motors, where its sealed design keeps contaminants out. The snap ring feature ensures secure mounting, making it ideal for compact spaces.

In automotive applications, 6201-2RSNR/C3 Bearing fits well in alternators and cooling fans, providing reliable radial load support. Its chrome steel construction offers durability even in high-temperature environments.

For home appliances, 6201-2RSNR/C3 Bearing works smoothly in washing machines and power tools, thanks to its low-maintenance sealed design. The C3 clearance allows for slight thermal expansion, ensuring consistent performance.

Where Is 6201-2RSNR/C3 Bearing Used?
You’ll often find 6201-2RSNR/C3 Bearing in office printers and scanners, where its quiet operation is a plus. The sealed construction also makes it suitable for dusty environments.

In robotics, 6201-2RSNR/C3 Bearing supports joint movements in lightweight arms, balancing speed and precision. The snap ring simplifies installation, saving time during assembly.

Built for Versatility: 6201-2RSNR/C3 Bearing
6201-2RSNR/C3 Bearing handles both radial and light axial loads, making it a flexible choice for DIY tools like drills. Its metric sizing ensures compatibility with most standard components.

Medical devices like small pumps benefit from 6201-2RSNR/C3 Bearing’s smooth rotation and sealed protection. The chrome steel materials meet hygiene standards for clinical environments.

Light-Duty vs Heavy-Duty: Best Uses for 6201-2RSNR/C3 Bearing
For light-duty tasks, 6201-2RSNR/C3 Bearing shines in ceiling fans and hobbyist gadgets. Its low weight and efficient design reduce energy consumption.

In heavier applications like industrial blowers, 6201-2RSNR/C3 Bearing’s robust build handles continuous operation. The C3 clearance accommodates thermal shifts without compromising performance.
