Snap Ring Groove Ball Bearings 6200-2RSHNR/C3GJN

Snap Ring Groove Ball Bearings 6200-2RSHNR/C3GJN

The 6200-2RSHNR/C3GJN is a compact snap ring groove ball bearing with a 10mm bore and 30mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1147 lbf and spins smoothly at speeds up to 24,000 RPM.

Its sealed design keeps dirt out and grease in, while the snap ring ensures a secure fit. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where space is limited.

Weighing just 32g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6200-2RSHNR/C3GJN
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 30 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 34.7 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 24000 rpm
  • Weight 32 g
  • Price（$） 2.8
Snap Ring Groove Ball Bearings 6200-2RSHNR/C3GJN dimension drawing
Download DWG Download PDF

Features

Why Choose 6200-2RSHNR/C3GJN Bearing for Precision Tasks?

6200-2RSHNR/C3GJN Bearing features a sealed design, protecting against dust and moisture for consistent performance.

Its chrome steel construction ensures durability and resistance to wear, even under radial loads up to 1147 lbf.

The snap ring fitted on the outer ring simplifies installation, saving time and effort.

With a maximum speed of 24,000 rpm, it delivers smooth operation in high-speed applications.

Application

Industrial Uses of 6200-2RSHNR/C3GJN Bearing
6200-2RSHNR/C3GJN Bearing is commonly used in conveyor systems, where its sealed design keeps out dust and debris, ensuring smooth operation. The snap ring feature makes installation quick and secure, ideal for high-speed production lines.

Where Is 6200-2RSHNR/C3GJN Bearing Used?
In automotive applications, 6200-2RSHNR/C3GJN Bearing fits well in electric motors and gearboxes, thanks to its radial load capacity. The C3 clearance allows for thermal expansion, making it reliable under varying temperatures.

Perfect Fit for Automation: 6200-2RSHNR/C3GJN Bearing
For robotic arms, 6200-2RSHNR/C3GJN Bearing offers precise movement with minimal maintenance. The chrome steel construction ensures durability, even in continuous operation.

Light-Duty vs Heavy-Duty: Best Uses for 6200-2RSHNR/C3GJN Bearing
In light-duty applications like printers, 6200-2RSHNR/C3GJN Bearing provides quiet performance. For heavier tasks, such as small machinery, its robust design handles radial loads effectively.

Medical vs Industrial: Where 6200-2RSHNR/C3GJN Bearing Excels
In medical devices, 6200-2RSHNR/C3GJN Bearing’s sealed design prevents contamination, crucial for hygiene. Industrial pumps benefit from its snap ring, which simplifies assembly and disassembly.
