Single Row Deep Groove Ball Bearings With Filling Slots 306

Single Row Deep Groove Ball Bearings With Filling Slots 306

The 306 is a single-row deep groove ball bearing with a 30mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6677 lbf and can spin at speeds reaching 11000 RPM.

Its open design with filling slots allows for easy lubrication, while the nylon cage reduces friction for smoother operation. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 0.37kg, it’s a balanced choice for its size, meeting RoHS and REACH standards for safety and environmental compliance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 306
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 19 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Grade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 6677 lbf
  • Static Radial Load 4856 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.37 kg
  • Price（$） 10.48
Single Row Deep Groove Ball Bearings With Filling Slots 306 dimension drawing
Download DWG Download PDF

Features

How Does 306 Bearing Reduce Friction?

306 Bearing features a deep groove design with filling slots, enhancing load distribution and reducing friction.
The chrome steel construction ensures durability and smooth operation under radial loads.

Its dynamic radial load capacity of 6677 lbf makes it suitable for high-performance applications.
The nylon cage minimises noise and wear, contributing to longer service life.

With a maximum speed of 11,000 rpm, 306 Bearing balances efficiency and reliability.
It operates effectively in temperatures ranging from -30° to 120°C, adapting to various environments.

Application

Industrial Uses of 306 Bearing
306 Bearing is commonly used in conveyor systems and industrial fans, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in dusty environments.

In automotive applications, 306 Bearing fits well in electric motors and alternators, providing smooth rotation under varying speeds. Its nylon cage reduces noise, making it suitable for quieter vehicle components.

For home appliances like washing machines, 306 Bearing’s chrome steel construction ensures durability against daily wear. The metric sizing makes it a reliable choice for European appliance manufacturers.

Where Is 306 Bearing Used?
You’ll often find 306 Bearing in small machinery such as pumps and compressors, where its radial load capacity is essential. The P0 tolerance class ensures consistent performance in precision applications.

In robotics, 306 Bearing supports joint movements in robotic arms, thanks to its balanced load distribution. The high-speed capability makes it ideal for automated production lines.

Built for Versatility: 306 Bearing
306 Bearing works well in both light-duty and heavy-duty scenarios, from office printers to agricultural equipment. Its temperature range allows it to perform reliably in various climates.

The chrome steel rings and balls provide good resistance to wear, even in high-use environments. This makes 306 Bearing a practical choice for long-term industrial use.
