Single Row Deep Groove Ball Bearings 6004TN9/C3

Single Row Deep Groove Ball Bearings 6004TN9/C3

The 6004TN9/C3 is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2113 lbf and can reach speeds of 17,000 RPM, making it a versatile choice.

Its open design and nylon cage ensure smooth operation, while the C3 radial clearance allows for thermal expansion in demanding conditions. The bearing performs reliably in temperatures from -30°C to 120°C.

Lightweight at just 69g, it’s easy to handle and install. Compliant with RoHS and REACH standards, this model is interchangeable with SKF bearings, ideal for motors, pumps, or small machinery where radial loads are common.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6004TN9/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2113 lbf
  • Static Radial Load 1135 lbf
  • Max Speed 17000 rpm
  • Weight 69 g
  • price（$） 3.861
Single Row Deep Groove Ball Bearings 6004TN9/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6004TN9/C3 Bearing

6004TN9/C3 Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its dynamic radial load capacity of 2113 lbf ensures steady performance in various applications.

The nylon cage in 6004TN9/C3 Bearing helps reduce friction and noise during operation.
With a maximum speed of 17,000 rpm, it is suitable for high-speed machinery.

6004TN9/C3 Bearing operates efficiently in temperatures ranging from -30° to 120°C.
Its open design allows for easy lubrication and maintenance.

The C3 radial clearance in 6004TN9/C3 Bearing accommodates thermal expansion, enhancing durability.
This makes it a practical choice for industrial and automotive uses.

Application

Industrial Uses of 6004TN9/C3 Bearing
6004TN9/C3 Bearing is commonly used in machine tools, where its radial load capacity and C3 clearance ensure smooth operation. The open design allows for easy lubrication, extending service life in demanding conditions.

Where Is 6004TN9/C3 Bearing Used?
You’ll often find 6004TN9/C3 Bearing in electric motors, thanks to its nylon cage reducing friction and noise. Its metric sizing makes it a versatile fit for various European and Asian equipment.

Perfect Fit for Automation: 6004TN9/C3 Bearing
In robotic arms, 6004TN9/C3 Bearing handles radial loads efficiently while maintaining precision. The chrome steel construction ensures durability even in high-speed applications.

Automotive vs Industrial: Applications of 6004TN9/C3 Bearing
In cars, 6004TN9/C3 Bearing supports alternators and water pumps, while in factories, it keeps conveyor systems running smoothly. Its temperature range suits both environments well.

Essential Roles of 6004TN9/C3 Bearing
For household appliances like washing machines, 6004TN9/C3 Bearing offers reliable performance with minimal maintenance. The lightweight design also helps reduce energy consumption.
