Single Row Deep Groove Ball Bearings 208M

Single Row Deep Groove Ball Bearings 208M

The 208M is a single-row deep groove ball bearing with a 40mm bore and 80mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7554 lbf and operates smoothly at speeds up to 9500 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective replacement option. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.39kg, it balances strength and lightness. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 208M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7554 lbf
  • Static Radial Load 6070 lbf
  • Max Speed 9500 rpm
  • Weight 0.39 kg
  • price（$） 10.269
Single Row Deep Groove Ball Bearings 208M dimension drawing
Download DWG Download PDF

Features

Performance Features of 208M Bearing

208M Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 7554 lbf, ensuring reliable performance in various applications.

The single-row deep groove design enhances stability and reduces friction during operation.
With a maximum speed of 9,500 rpm, it balances efficiency and durability.

208M Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open seal type allows for easy maintenance and lubrication adjustments.

Application

Industrial Uses of 208M Bearing
208M Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending its service life in demanding environments.

Where Is 208M Bearing Used?
In automotive applications, 208M Bearing fits well in components such as alternators and wheel hubs, providing reliable performance under radial loads. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Versatility: 208M Bearing
For household appliances like washing machines, 208M Bearing offers durability and quiet operation. The chrome steel construction ensures it can handle everyday wear and tear with ease.

Automotive vs Industrial: Applications of 208M Bearing
In robotics, 208M Bearing is ideal for joints and gears, thanks to its precise radial load handling. The ABEC 1 tolerance ensures consistent performance in both light and heavy-duty applications.
