Single Row Cylindrical Roller Bearings With Inner Ring NU 205 ECP

Single Row Cylindrical Roller Bearings With Inner Ring NU 205 ECP

The NU 205 ECP is a single row cylindrical roller bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 7312 lbf and reaches speeds of 16000 RPM with ease.

Its open design allows for simple lubrication with grease or oil, while the PA66 cage ensures smooth operation. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery like pumps or electric motors where radial and axial loads are present.

Weighing just 0.13kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number NU 205 ECP
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.12mm to 0
  • Chamfer Dimension r1,2(min.) 1 mm
  • Chamfer Dimension r3,4(min.) 0.6 mm
  • Permissible Axial Displacement(max.) 1.3 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • For Load Direction Combined
  • Construction Single Row
  • Inner Ring Type With Inner Ring
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material PA66 cage, roller centred
  • Dynamic Radial Load 7312 lbf
  • Static Radial Load 6075 lbf
  • Lubrication Grease, Oil
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 16000 rpm
  • Weight 0.13 kg
  • Shoulder Dia Of Outer Ring 43.3 mm
  • Raceway Diameter Of Inner Ring 31.5 mm
Single Row Cylindrical Roller Bearings With Inner Ring NU 205 ECP dimension drawing
Download DWG Download PDF

Features

Performance Features of NU 205 ECP Bearing

NU 205 ECP Bearing is crafted with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 7312 lbf, ensuring reliable performance in various applications.

The PA66 cage keeps the rollers centred, reducing friction and extending service life.
With a maximum speed of 16,000 rpm, it balances durability and efficiency.

NU 205 ECP Bearing operates smoothly in temperatures ranging from -30° to 110°C.
Its open design allows for easy lubrication with grease or oil, reducing maintenance needs.

The precise chamfer dimensions of 1 mm and 0.6 mm ensure easy installation and alignment.
This bearing is ideal for applications requiring high-speed performance and long-lasting reliability.

Application

Industrial Uses of NU 205 ECP Bearing
NU 205 ECP Bearing is commonly used in industrial machinery like pumps and compressors, where its cylindrical roller design handles combined loads efficiently. The open seal type simplifies lubrication, making it suitable for high-speed operations up to 16000 rpm.

Where Is NU 205 ECP Bearing Used?
In automotive applications, NU 205 ECP Bearing fits well in gearboxes and transmissions, thanks to its chrome steel construction and reliable performance. Its metric sizing ensures compatibility with a variety of vehicle models.

Perfect Fit for Automation: NU 205 ECP Bearing
NU 205 ECP Bearing works seamlessly in robotic arms and automated systems, where precision and durability are key. The PA66 cage reduces friction, enhancing its lifespan in continuous operation.

Medical vs Industrial: Where NU 205 ECP Bearing Excels
NU 205 ECP Bearing is versatile enough for medical imaging devices, offering smooth rotation and stability. In industrial settings, it’s a go-to for conveyor systems due to its high load capacity.

Essential Roles of NU 205 ECP Bearing
NU 205 ECP Bearing supports heavy-duty equipment like electric motors, where its static radial load capacity of 6075 lbf ensures reliability. The temperature range of -30° to 110°C makes it adaptable to various environments.
