RN-0.5x6 BF RN-1x7.8 BF/G2

RN-0.5×6 BF RN-1×7.8 BF/G2

This needle roller bearing features a compact design with a 1mm diameter and 7.8mm length, made from tough chrome steel for durability. It meets G2 precision standards, ensuring smooth operation with minimal vibration.

The flat ends and high hardness (HRC60-65) make it resistant to wear, while the tight length tolerance (0 to -0.22mm) ensures a precise fit. Its roundness is finely tuned to 0.5um for consistent performance.

With low axial and radial runout (Rsmax 0.5mm and 0.3mm respectively), it’s ideal for high-precision applications. The bearing is RoHS compliant, making it safe for various industrial uses.

Perfect for compact machinery or automotive systems where space is limited but performance can’t be compromised. Interchangeable with INA bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number RN-1x7.8 BF/G2
  • Brand TFL
  • Interchangeable INA
  • Roller Diameter 1 mm
  • Roller Length 7.8 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Material Chrome Steel
  • RoHS Compliant
  • Rating G2
  • Length Tolerance 0 to -0.22 mm
  • Hardness HRC60-65
  • Ends Type Flat
  • Roundness 0.5um
  • VDWL 2um
  • Rsmax Axial 0.5 mm
  • Rsmax Radial 0.3 mm
  • Rsmin 0.1 mm

Features

How Does RN-1×7.8 BF/G2 Bearing Reduce Friction?

RN-1×7.8 BF/G2 Bearing features precision-ground chrome steel rollers with a diameter of 1 mm and length of 7.8 mm, ensuring smooth operation.
The needle roller design minimises contact area, effectively reducing friction in compact spaces.
With a hardness rating of HRC60-65, it maintains performance under high-stress conditions.
Its tight roundness tolerance of 0.5µm contributes to consistent rolling motion.

Application

Industrial Uses of RN-1×7.8 BF/G2 Bearing
RN-1×7.8 BF/G2 Bearing is commonly used in compact industrial gearboxes, where its small size and high load capacity make it ideal for tight spaces. The chrome steel construction ensures durability even in demanding conditions.

Where Is RN-1×7.8 BF/G2 Bearing Used?
You’ll often find RN-1×7.8 BF/G2 Bearing in automotive transmissions, where its needle rollers handle high radial loads efficiently. The flat ends design helps in smooth rotation and reduces friction.

Perfect Fit for Automation: RN-1×7.8 BF/G2 Bearing
RN-1×7.8 BF/G2 Bearing works well in robotic arms, providing precise movement thanks to its tight roundness tolerance. The G2 rating ensures consistent performance in high-speed applications.

Medical vs Industrial: Where RN-1×7.8 BF/G2 Bearing Excels
In medical devices like surgical tools, RN-1×7.8 BF/G2 Bearing offers reliable precision due to its minimal radial play. For industrial use, its hardness and wear resistance make it suitable for heavy machinery.

Essential Roles of RN-1×7.8 BF/G2 Bearing
RN-1×7.8 BF/G2 Bearing is a go-to choice for printers and copiers, where its small dimensions and smooth operation are key. The chrome steel material also resists corrosion, extending its lifespan.
