LM763848 Single Cones (Imperial)

LM763848 Single Cones (Imperial)

The LM763848 is a single-row tapered roller bearing cone with a 14.25-inch bore, designed for combined loads. Made from sturdy chrome steel, it handles dynamic radial loads up to 228,000 lbf and static loads up to 498,000 lbf.

Its open design allows easy lubrication, while the steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial machinery or large vehicles where combined loads are common.

With standard radial clearance and ABEC-1 rating, it offers reliable performance. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number LM763848
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Inch
  • Type Cones
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Series LM763800
  • Bore Dia 14.25"
  • Bore Dia Tolerance +0.001" to 0
  • Cone Width 2.5"
  • Cone Width Tolerance +0.003" to -0.01
  • Cone Backface ToClear Radius 0.13"
  • Cone Frontface Backing Diameter 14.96"
  • Cone Backface Backing Diameter 15.08"
  • Cage Cone Frontface Clearance 0.22"
  • Cage Cone Backface Clearance 0.13"
  • Effective Center Location 1.19"
  • Ring Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 228000 lbf
  • Static Radial Load 498000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 59000 lbf
  • Dynamic Radial Rating(Two Row 1 Million Revolutions)(C1) 396000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 47800 lbf
  • Dynamic Radial Rating(Two Row 90 Million Revolutions)(C90) 103000 lbf
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant

Features

How Is LM763848 Bearing Engineered for Reliability?

LM763848 Bearing is crafted from chrome steel, offering strong resistance to combined loads with a dynamic radial load capacity of 228,000 lbf.
Its tapered roller design ensures smooth operation and efficient load distribution, enhancing durability.
The steel cage maintains proper roller alignment, reducing friction and wear over time.
With a temperature range of -30° to 110°C, it performs reliably in varied conditions.

What Makes LM763848 Bearing Suitable for High-Temperature Applications?

LM763848 Bearing operates effectively in temperatures up to 110°C, maintaining performance in demanding environments.
Its chrome steel construction provides excellent heat resistance, ensuring long-term reliability.
The open seal design allows for better heat dissipation, preventing overheating.
With a static radial load capacity of 498,000 lbf, it handles heavy loads with ease.

Built for Durability: LM763848 Bearing

LM763848 Bearing features a robust chrome steel construction, designed to withstand heavy combined loads.
Its tapered roller design ensures efficient load distribution, reducing stress on components.
The steel cage keeps rollers in place, minimising wear and extending service life.
With standard radial clearance options, it offers flexibility for various applications.

Steel vs Ceramic Bearings: Strengths of LM763848 Bearing

LM763848 Bearing uses high-quality chrome steel, providing superior strength and durability for industrial use.
Its tapered roller design ensures reliable performance under combined loads, with a dynamic radial rating of 228,000 lbf.
The steel cage enhances stability, reducing friction and maintenance needs.
With an ABEC-1 rating, it balances precision and cost-effectiveness.

Why Choose LM763848 Bearing for Precision Tasks?

LM763848 Bearing offers precise performance with its tapered roller design and chrome steel construction.
Its effective center location of 1.19″ ensures accurate alignment in machinery.
The open seal design allows for easy inspection and maintenance, reducing downtime.
With a dynamic thrust rating of 47,800 lbf, it handles both radial and axial loads efficiently.

Application

Industrial Uses of LM763848 Bearing
LM763848 Bearing is commonly used in heavy machinery, such as construction equipment and mining tools, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability in demanding environments.

Where Is LM763848 Bearing Used?
You’ll find LM763848 Bearing in industrial gearboxes and large conveyor systems, thanks to its high dynamic radial load capacity. Its inch sizing makes it a preferred choice for machinery requiring imperial measurements.

Built for Heavy-Duty Use: LM763848 Bearing
LM763848 Bearing excels in applications like railway axles and agricultural machinery, where reliability under heavy loads is essential. The steel cage adds extra strength, making it suitable for long-term use.

Automotive vs Aerospace: Applications of LM763848 Bearing
In automotive systems, LM763848 Bearing supports wheel hubs and drivetrains, while in aerospace, it’s used in landing gear for its high load capacity. The temperature range ensures performance in varied conditions.

Key Fields for LM763848 Bearing
LM763848 Bearing is ideal for wind turbines and marine equipment, where its tapered rollers manage radial and thrust loads efficiently. The ABEC-1 rating provides balanced precision for these applications.
