Drawn Cup Needle Roller Bearings BCE58-P

Drawn Cup Needle Roller Bearings BCE58-P

The BCE58-P is a drawn cup needle roller bearing with a 0.3125″ bore and 0.5″ outer diameter, crafted from sturdy steel. It handles radial loads up to 1057 lbf and can spin at speeds up to 23,000 RPM.
Its single-seal design keeps contaminants out while maintaining smooth operation. The press-fit mounting ensures a secure attachment to shafts.
This bearing is ideal for compact spaces where high load capacity is needed, such as in automotive transmissions or small machinery. It requires regular lubrication for optimal performance.
Compatible with INA bearings, it offers a reliable replacement option. Suitable for temperatures ranging from -20°C to 110°C, it’s a versatile choice for various applications.
The closed-end design adds durability, making it a practical pick for demanding environments. RoHS compliant for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCE58-P
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.3125"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 0.5"
  • Outer Dia Tolerance Not Rated
  • Width 0.5"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Single Seal
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 1057 lbf
  • Static Radial Load 109 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 23000 rpm
  • Weight 6 g
Drawn Cup Needle Roller Bearings BCE58-P dimension drawing
Download DWG Download PDF

Features

How Does BCE58-P Bearing Handle High-Speed Applications?
BCE58-P Bearing is built with steel rings and needles, offering strong radial load support up to 1057 lbf.
Its press-fit design ensures secure mounting, making it ideal for compact spaces.
The single-seal construction helps retain lubrication, extending maintenance intervals.
With a maximum speed of 23,000 rpm, it delivers reliable performance in high-speed scenarios.

Application

Industrial Uses of BCE58-P Bearing
BCE58-P Bearing is commonly used in industrial machinery, especially in compact spaces where high radial load capacity is needed, such as conveyor systems and gearboxes. Its single seal design helps keep contaminants out while maintaining smooth operation.
Where Is BCE58-P Bearing Used?
In automotive applications, BCE58-P Bearing fits well in components like transmissions and steering systems, thanks to its press-fit mounting and high-speed capability. The steel construction ensures durability even under continuous use.
Perfect Fit for Automation: BCE58-P Bearing
For automation and robotics, BCE58-P Bearing provides reliable performance in robotic arms and linear actuators, where precision and low friction are key. Its closed-end design helps retain lubrication for longer service life.
Medical vs Industrial: Where BCE58-P Bearing Excels
While BCE58-P Bearing is versatile for industrial tools, it also suits medical devices like small pumps and lab equipment, where its compact size and consistent performance are beneficial. The inch sizing makes it compatible with various international standards.
Essential Roles of BCE58-P Bearing
In consumer electronics, BCE58-P Bearing can be found in devices like printers and small motors, offering quiet and efficient operation. Its steel needle rollers handle radial loads effectively, making it a practical choice for everyday gadgets.
