Double Row Cylindrical Roller Thrust Bearings 89416 M

Double Row Cylindrical Roller Thrust Bearings 89416 M

The 89416 M is a double-row cylindrical roller thrust bearing, measuring 80mm in bore diameter and 170mm in outer diameter, with a width of 54mm. Made from chrome steel, it’s built to handle heavy thrust loads up to 389250 lbf.

Its two-row roller design provides extra stability and load capacity, while the machined brass cage ensures smooth operation. It can handle speeds up to 1800 RPM and works in temperatures from -30°C to 110°C.

The bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial presses or large gearboxes where high thrust loads are common.

Weighing 7.04kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89416 M
  • Size 80 mm x 170 mm x 54 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 54 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 170 mm
  • Bore Diameter Housing Washer 83 mm
  • Height Shaft Washer 18 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 2.1 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 99000 lbf
  • Static Radial Load 389250 lbf
  • Max Speed 1800 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 7.04 kg
  • Roller And Cage Thrust Assembly K 89416 M
  • Shaft Washer WS 89416
  • Housing Washer GS 89416
Double Row Cylindrical Roller Thrust Bearings 89416 M dimension drawing
Download DWG Download PDF

Features

How Does 89416 M Bearing Handle Heavy Loads?

89416 M Bearing features a double-row cylindrical roller design, optimised for high thrust load capacity.
Its dynamic radial load rating of 99,000 lbf ensures robust performance in heavy-duty applications.

The machined brass cage maintains roller alignment, reducing friction and wear.
Chrome steel construction enhances durability, even under extreme conditions.

With a maximum speed of 1,800 rpm, 89416 M Bearing balances power and efficiency.
Its temperature range of -30° to 110°C makes it suitable for varied environments.

Designed for easy installation, 89416 M Bearing reduces maintenance efforts.
The precision tolerances ensure smooth operation and long service life.

Application

Industrial Uses of 89416 M Bearing
89416 M Bearing is commonly used in heavy machinery like presses and rolling mills, where its double-row design handles high thrust loads efficiently. The machined brass cage ensures smooth operation even under demanding conditions.

Where Is 89416 M Bearing Used?
You’ll often find 89416 M Bearing in wind turbines and industrial gearboxes, thanks to its robust chrome steel construction. Its precise tolerances make it ideal for applications requiring reliable axial load support.

Built for Heavy-Duty Use: 89416 M Bearing
89416 M Bearing excels in construction equipment, such as cranes and excavators, where durability is key. The large bore diameter and high static load capacity make it a solid choice for tough environments.

Automotive vs Aerospace: Applications of 89416 M Bearing
In automotive systems, 89416 M Bearing supports transmissions and differentials, while in aerospace, it’s used in landing gear mechanisms. Its temperature range and load capacity suit both industries well.

Practical Applications of 89416 M Bearing
For conveyor systems and material handling equipment, 89416 M Bearing offers long-lasting performance. The metric sizing and interchangeable design with SKF make it a versatile option for global suppliers.
