Double Row Cylindrical Roller Thrust Bearings 89414 TN

Double Row Cylindrical Roller Thrust Bearings 89414 TN

The 89414 TN is a double-row cylindrical roller thrust bearing, measuring 70mm in bore diameter and 150mm in outer diameter, with a width of 48mm. Made from durable chrome steel, it handles heavy thrust loads up to 85500 lbf and operates smoothly at speeds up to 2000 RPM.

Its two-row roller design provides excellent load distribution, while the glass fibre reinforced PA66 cage ensures reliable performance. The bearing works well in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or large machinery where high thrust loads are common.

Weighing 4.18kg, it’s built to last and complies with RoHS and REACH standards for safe use. The shaft and housing washers are included for easy installation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89414 TN
  • Size 70 mm x 150 mm x 48 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 48 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 150 mm
  • Bore Diameter Housing Washer 73 mm
  • Height Shaft Washer 16 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 2 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 85500 lbf
  • Static Radial Load 328500 lbf
  • Max Speed 2000 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 4.18 kg
  • Roller And Cage Thrust Assembly K 89414 TN
  • Shaft Washer WS 89414
  • Housing Washer GS 89414
Double Row Cylindrical Roller Thrust Bearings 89414 TN dimension drawing
Download DWG Download PDF

Features

Performance Features of 89414 TN Bearing

89414 TN Bearing is built with chrome steel washers and rollers, offering strong resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 85,500 lbf, ensuring reliable operation in demanding conditions.

The glass fibre reinforced PA66 cage keeps the rollers aligned, reducing friction and extending service life.
With a maximum speed of 2,000 rpm, it balances durability and efficiency for industrial applications.

Designed for high-load scenarios, 89414 TN Bearing performs well in temperatures from -30° to 110°C.
Its precise tolerances and robust construction make it a dependable choice for thrust applications.

Application

Industrial Uses of 89414 TN Bearing
The 89414 TN Bearing is commonly used in heavy machinery like presses and extruders, where its double-row design handles significant thrust loads. Its chrome steel construction ensures durability in demanding industrial environments.

In automotive applications, 89414 TN Bearing supports gearboxes and drivetrains, providing reliable performance under high stress. The glass fibre reinforced cage enhances its resistance to wear and heat.

For automation systems, 89414 TN Bearing is ideal for robotic arms and conveyor belts, offering smooth operation at high speeds. Its metric sizing makes it compatible with a variety of European and Asian equipment.

Medical equipment like MRI machines benefit from 89414 TN Bearing’s precision and stability. The PA66 cage material ensures quiet operation, crucial for sensitive medical environments.

In consumer electronics, 89414 TN Bearing can be found in high-performance printers and industrial fans. Its robust design ensures long-lasting performance even with continuous use.
