Double Row Cylindrical Roller Thrust Bearings 89413 TN

Double Row Cylindrical Roller Thrust Bearings 89413 TN

The 89413 TN is a double-row cylindrical roller thrust bearing, measuring 65mm in bore diameter and 140mm in outer diameter, with a width of 45mm. Made from chrome steel, it’s built to handle heavy thrust loads up to 79875 lbf.

Its two rows of rollers provide stability and even load distribution, while the glass fibre reinforced PA66 cage ensures durability. The bearing operates smoothly at speeds up to 2200 RPM.

The design includes precise tolerances and a 2mm chamfer for easy installation. It works well in temperatures ranging from -30°C to 110°C.

Ideal for industrial machinery like gearboxes or presses, where high thrust loads are common. Compliant with RoHS and REACH standards, it’s a reliable choice for replacements, interchangeable with SKF models. Weighing 3.52kg, it’s robust yet manageable for its size.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89413 TN
  • Size 65 mm x 140 mm x 45 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 45 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 140 mm
  • Bore Diameter Housing Washer 68 mm
  • Height Shaft Washer 15 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 2 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 79875 lbf
  • Static Radial Load 308250 lbf
  • Max Speed 2200 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 3.52 kg
  • Roller And Cage Thrust Assembly K 89413 TN
  • Shaft Washer WS 89413
  • Housing Washer GS 89413
Double Row Cylindrical Roller Thrust Bearings 89413 TN dimension drawing
Download DWG Download PDF

Features

How Does 89413 TN Bearing Handle Heavy Loads?

89413 TN Bearing features double-row cylindrical rollers, designed to manage high thrust loads efficiently.
Its dynamic radial load capacity reaches 79,875 lbf, making it suitable for demanding industrial applications.
The chrome steel rollers and washers ensure durability, while the glass fibre reinforced PA66 cage maintains alignment.
With a maximum speed of 2,200 rpm, it balances performance and reliability in various conditions.

What Makes 89413 TN Bearing Suitable for High-Temperature Applications?

89413 TN Bearing operates reliably in temperatures ranging from -30° to 110°C.
The chrome steel construction resists thermal expansion, maintaining stability under heat.
Its glass fibre reinforced PA66 cage also withstands high temperatures without degrading.
This makes it ideal for applications where consistent performance in varying temperatures is crucial.

Engineered for Precision: 89413 TN Bearing

89413 TN Bearing’s double-row cylindrical rollers ensure precise load distribution.
The tight tolerances on bore and outer diameters enhance alignment and reduce vibration.
Its glass fibre reinforced PA66 cage minimises friction, contributing to smooth operation.
This precision engineering makes it a dependable choice for high-performance machinery.

Why Choose 89413 TN Bearing for Thrust Applications?

89413 TN Bearing is specifically designed for thrust loads, with a static radial load capacity of 308,250 lbf.
The double-row roller configuration distributes forces evenly, reducing wear.
Its chrome steel components and reinforced cage ensure long-term reliability.
This makes it a robust solution for heavy-duty thrust applications.

Structural Advantages of 89413 TN Bearing

89413 TN Bearing’s double-row design increases load-bearing capacity without compromising space.
The chrome steel washers and rollers provide excellent resistance to deformation under pressure.
Its glass fibre reinforced PA66 cage offers lightweight yet durable support.
These structural features make it a versatile choice for various industrial uses.

Application

Industrial Uses of 89413 TN Bearing
The 89413 TN Bearing is commonly used in heavy machinery like presses and extruders, where its double-row design handles significant axial loads with ease. Its chrome steel construction ensures durability in demanding industrial environments.

What Makes 89413 TN Bearing a Preferred Choice?
In automotive applications, 89413 TN Bearing supports gearboxes and drivetrains, providing reliable performance under high thrust loads. The glass fibre reinforced cage adds stability, making it suitable for high-speed operations.

Built for Heavy-Duty Use: 89413 TN Bearing
For automation systems, 89413 TN Bearing excels in robotic arms and conveyor belts, where precision and load capacity are key. Its metric sizing ensures compatibility with a wide range of equipment.

Medical vs Industrial: Where 89413 TN Bearing Excels
While 89413 TN Bearing is robust enough for industrial presses, its precision also suits medical imaging devices. The temperature range and material quality make it versatile across sectors.

Where Is 89413 TN Bearing Used?
In consumer electronics like high-power printers, 89413 TN Bearing ensures smooth operation under consistent loads. Its design minimizes friction, extending the lifespan of the device.
