Double Row Cylindrical Roller Thrust Bearings 89316 TN

Double Row Cylindrical Roller Thrust Bearings 89316 TN

The 89316 TN is a double-row cylindrical roller thrust bearing with an 80mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It manages heavy thrust loads up to 238500 lbf and operates smoothly at speeds up to 2400 RPM.

Its reinforced PA66 cage ensures durability, while the double-row design provides extra stability under pressure. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Perfect for heavy-duty applications like industrial presses or large gear systems where high thrust loads are expected.

Weighing 2.37kg, it’s built to last while maintaining precision. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89316 TN
  • Size 80 mm x 140 mm x 36 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 36 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 140 mm
  • Bore Diameter Housing Washer 82 mm
  • Height Shaft Washer 12.5 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 1.5 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 54000 lbf
  • Static Radial Load 238500 lbf
  • Max Speed 2400 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.37 kg
  • Roller And Cage Thrust Assembly K 89316 TN
  • Shaft Washer WS 89316
  • Housing Washer GS 89316
Double Row Cylindrical Roller Thrust Bearings 89316 TN dimension drawing
Download DWG Download PDF

Features

How Does 89316 TN Bearing Handle Heavy Loads?

89316 TN Bearing features double-row cylindrical rollers, designed to manage high thrust loads efficiently.
Its dynamic radial load capacity reaches 54000 lbf, making it suitable for heavy-duty applications.

The chrome steel rollers and washers ensure durability, while the glass fibre reinforced PA66 cage maintains alignment.
With a maximum speed of 2400 rpm, it balances performance and reliability in demanding conditions.

89316 TN Bearing operates smoothly within a temperature range of -30° to 110°C.
Its robust construction reduces maintenance needs, offering long service life even under stress.

Application

Key Fields for 89316 TN Bearing
89316 TN Bearing is widely used in industrial machinery, especially in heavy-duty applications like presses and rolling mills. Its double-row cylindrical roller design handles high thrust loads efficiently, ensuring reliable performance in demanding environments.

In automotive systems, 89316 TN Bearing supports components such as transmissions and differentials, where its robust construction withstands constant stress. The glass fibre reinforced cage adds durability, making it suitable for long-term use.

For automation equipment, 89316 TN Bearing provides smooth operation in robotic arms and assembly lines. Its precise tolerances and high load capacity make it a dependable choice for precision-driven tasks.

Medical imaging devices benefit from 89316 TN Bearing’s stability and low maintenance requirements. The chrome steel rollers ensure consistent performance, even in high-speed rotations.

In consumer electronics, 89316 TN Bearing can be found in heavy-duty printers and industrial fans. Its balanced design reduces vibration, contributing to quieter operation and extended lifespan.
