Double Row Cylindrical Roller Thrust Bearings 89306 TN

Double Row Cylindrical Roller Thrust Bearings 89306 TN

The 89306 TN is a double-row cylindrical roller thrust bearing, measuring 30mm by 60mm by 18mm, crafted from sturdy chrome steel. It handles heavy thrust loads up to 11700 lbf and operates smoothly at speeds up to 5300 RPM.

Its two-row roller design distributes loads evenly, while the glass fibre reinforced PA66 cage ensures durability and reduced friction. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for heavy-duty applications like industrial gearboxes or machinery with high thrust demands.

Weighing just 0.24kg, it’s compact yet robust. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89306 TN
  • Size 30 mm x 60 mm x 18 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.010mm to 0
  • Outer Dia 60 mm
  • Outer Dia Tolerance -0.019mm to 0
  • Width 18 mm
  • Height Tolerance -0.25mm to +0.02mm
  • Outside Diameter Shaft Washer 60 mm
  • Bore Diameter Housing Washer 32 mm
  • Height Shaft Washer 6.25 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 1 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 11700 lbf
  • Static Radial Load 41175 lbf
  • Max Speed 5300 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.24 kg
  • Roller And Cage Thrust Assembly K 89306 TN
  • Shaft Washer WS 89306
  • Housing Washer GS 89306
Double Row Cylindrical Roller Thrust Bearings 89306 TN dimension drawing
Download DWG Download PDF

Features

How Does 89306 TN Bearing Handle Heavy Thrust Loads?

89306 TN Bearing features a double-row cylindrical roller design, optimised for high thrust load capacity.
Its dynamic radial load rating of 11700 lbf ensures reliable performance in demanding applications.

The chrome steel rollers and washers provide excellent durability under heavy loads.
With a reinforced PA66 cage, 89306 TN Bearing maintains alignment and reduces wear.

Operating at speeds up to 5300 rpm, it balances efficiency and strength.
Its temperature range of -30° to 110°C makes it suitable for various environments.

Application

Industrial Uses of 89306 TN Bearing
89306 TN Bearing is commonly used in heavy machinery, such as presses and extruders, where its double-row design handles high thrust loads efficiently. The glass fibre reinforced PA66 cage ensures smooth operation even at high speeds.

Where Is 89306 TN Bearing Used?
In automotive applications, 89306 TN Bearing supports gearboxes and differential systems, providing reliable performance under demanding conditions. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: 89306 TN Bearing
For automation systems, 89306 TN Bearing is ideal for robotic arms and conveyor belts, thanks to its durable chrome steel construction. The precise tolerances ensure consistent performance in repetitive tasks.

Medical vs Industrial: Where 89306 TN Bearing Excels
In medical devices like MRI machines, 89306 TN Bearing offers quiet and reliable operation. Its industrial counterpart shines in heavy-load scenarios, such as construction equipment, due to its robust design.

Practical Applications of 89306 TN Bearing
89306 TN Bearing is a great fit for household appliances like washing machines, where its high-speed capability and low maintenance are key advantages. The temperature range also makes it suitable for various climates.
