Product Parameters

Part Number XAA33019-Y33019
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 95 mm x 145 mm x 39 mm
Cone Part Number XAA33019
Cup Part Number Y33019
Bore Dia 95 mm
Bore Dia Tolerance -0.02mm to 0
Outer Dia 145 mm
Outer Dia Tolerance -0.02mm to 0
Cone Width 39 mm
Cone Width Tolerance -0.15mm to 0
Cup Width 32.5 mm
Cup Width Tolerance -0.2mm to 0
Width 39 mm
Width Tolerance +0.2mm to -0.2mm
Cone Backface ToClear Radius 6.1 mm
Cup Backface ToClear Radius 1.52 mm
Cone Frontface Backing Diameter 102 mm
Cone Backface Backing Diameter 114 mm
Cup Frontface Backing Diameter 139.95 mm
Cup Backface Backing Diameter 133.10 mm
Cage Cone Frontface Clearance 3 mm
Cage Cone Backface Clearance 1.3 mm
Effective Center Location -10.2 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 33019
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 55350 lbf
Static Radial Load 85050 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 14355 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 6840 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 4.85 lb
