Product Parameters

Part Number X32032-Y32032
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 160 mm x 240 mm x 51 mm
Cone Part Number X32032
Cup Part Number Y32032
Bore Dia 160 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 240 mm
Outer Dia Tolerance -0.03mm to 0
Cone Width 51 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 38 mm
Cup Width Tolerance -0.25mm to 0
Width 51 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 3.05 mm
Cup Backface ToClear Radius 2.54 mm
Cone Frontface Backing Diameter 169.9 mm
Cone Backface Backing Diameter 181.1 mm
Cup Frontface Backing Diameter 231.39 mm
Cup Backface Backing Diameter 219.96 mm
Cage Cone Frontface Clearance 4.6 mm
Cage Cone Backface Clearance 4.1 mm
Effective Center Location 1.5 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32032
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 116100 lbf
Static Radial Load 180225 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 30150 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 23625 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 16.53 lb
