Product Parameters

Part Number JP16049-JP16010
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 160 mm x 220 mm x 32 mm
Cone Part Number JP16049
Cup Part Number JP16010
Bore Dia 160 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 220 mm
Outer Dia Tolerance -0.03mm to 0
Cone Width 30 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 23 mm
Cup Width Tolerance -0.25mm to 0
Width 32 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 3.05 mm
Cup Backface ToClear Radius 3.05 mm
Cone Frontface Backing Diameter 169 mm
Cone Backface Backing Diameter 174 mm
Cup Frontface Backing Diameter 214.10 mm
Cup Backface Backing Diameter 205.99 mm
Cage Cone Frontface Clearance 4.8 mm
Cage Cone Backface Clearance 3 mm
Effective Center Location 13 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series JP16000
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 54450 lbf
Static Radial Load 83700 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 14107.5 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 11745 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 6.83 lb
