Product Parameters

Part Number JM738249A-JM738210
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 190 mm x 260 mm x 46 mm
Cone Part Number JM738249A
Cup Part Number JM738210
Bore Dia 190 mm
Bore Dia Tolerance -0.03mm to 0
Outer Dia 260 mm
Outer Dia Tolerance -0.035mm to 0
Cone Width 44 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 36.5 mm
Cup Width Tolerance -0.25mm to 0
Width 46 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 7.87 mm
Cup Backface ToClear Radius 2.54 mm
Cone Frontface Backing Diameter 200 mm
Cone Backface Backing Diameter 215 mm
Cup Frontface Backing Diameter 252.22 mm
Cup Backface Backing Diameter 242.06 mm
Cage Cone Frontface Clearance 4.8 mm
Cage Cone Backface Clearance 2.5 mm
Effective Center Location 10.9 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series M738200
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 91575 lbf
Static Radial Load 181575 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 23625 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 19395 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 14.99 lb
