Product Parameters

Part Number J450590-J451161
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 150 mm x 295 mm x 80 mm
Cone Part Number J450590
Cup Part Number J451161
Bore Dia 150 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 295 mm
Outer Dia Tolerance -0.035mm to 0
Cone Width 80 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 61.912 mm
Cup Width Tolerance -0.25mm to 0
Width 80 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 5.08 mm
Cup Backface ToClear Radius 5.08 mm
Cone Frontface Backing Diameter 175 mm
Cone Backface Backing Diameter 179 mm
Cup Frontface Backing Diameter 275.10 mm
Cup Backface Backing Diameter 267.97 mm
Cage Cone Frontface Clearance 3 mm
Cage Cone Backface Clearance 8.4 mm
Effective Center Location -19.3 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 450000
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 223650 lbf
Static Radial Load 333000 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 58050 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 32400 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 53.13 lb
