Product Parameters

Part Number 33030
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 150 mm x 225 mm x 59 mm
Cone Part Number X33030M
Cup Part Number Y33030M
Bore Dia 150 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 225 mm
Outer Dia Tolerance -0.03mm to 0
Cone Width 59 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 46 mm
Cup Width Tolerance -0.25mm to 0
Width 59 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 3 mm
Cup Backface ToClear Radius 2.5 mm
Cone Frontface Backing Diameter 161 mm
Cone Backface Backing Diameter 169 mm
Cup Frontface Backing Diameter 218 mm
Cup Backface Backing Diameter 207 mm
Cage Cone Frontface Clearance 4.6 mm
Cage Cone Backface Clearance 4.6 mm
Effective Center Location -10.9 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 33030
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 126225 lbf
Static Radial Load 213525 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 32625 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 20430 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 17.64 lb
