Product Parameters

Part Number 32968
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 340 mm x 460 mm x 76 mm
Cone Part Number X32968M
Cup Part Number Y32968M
Bore Dia 340 mm
Bore Dia Tolerance -0.04mm to 0
Outer Dia 460 mm
Outer Dia Tolerance -0.045mm to 0
Cone Width 76 mm
Cone Width Tolerance -0.25mm to 0
Cup Width 57 mm
Cup Width Tolerance -0.3mm to 0
Width 76 mm
Width Tolerance +0.4mm to -0.4mm
Cone Backface ToClear Radius 4.06 mm
Cup Backface ToClear Radius 3.05 mm
Cone Frontface Backing Diameter 359 mm
Cone Backface Backing Diameter 364 mm
Cup Frontface Backing Diameter 449.30 mm
Cup Backface Backing Diameter 432.05 mm
Cage Cone Frontface Clearance 5.6 mm
Cage Cone Backface Clearance 9.1 mm
Effective Center Location 14.7 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32968M
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 274500 lbf
Static Radial Load 594000 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 71100 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 53325 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 76.06 lb
