Product Parameters

Part Number 32930
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 150 mm x 210 mm x 38 mm
Cone Part Number X32930M
Cup Part Number Y32930M
Bore Dia 150 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 210 mm
Outer Dia Tolerance -0.03mm to 0
Cone Width 38 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 30 mm
Cup Width Tolerance -0.25mm to 0
Width 38 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 2.54 mm
Cup Backface ToClear Radius 2.03 mm
Cone Frontface Backing Diameter 160 mm
Cone Backface Backing Diameter 163 mm
Cup Frontface Backing Diameter 204.00 mm
Cup Backface Backing Diameter 197.10 mm
Cage Cone Frontface Clearance 3.6 mm
Cage Cone Backface Clearance 2 mm
Effective Center Location -1.5 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32930M
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 72900 lbf
Static Radial Load 128925 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 18900 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 10620 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 8.82 lb
