Product Parameters

Part Number 32248
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 240 mm x 440 mm x 127 mm
Cone Part Number X32248
Cup Part Number Y32248
Bore Dia 240 mm
Bore Dia Tolerance -0.03mm to 0
Outer Dia 440 mm
Outer Dia Tolerance -0.045mm to 0
Cone Width 120 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 100 mm
Cup Width Tolerance -0.3mm to 0
Width 127 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 5 mm
Cup Backface ToClear Radius 4 mm
Cone Frontface Backing Diameter 280 mm
Cone Backface Backing Diameter 293 mm
Cup Frontface Backing Diameter 415 mm
Cup Backface Backing Diameter 394 mm
Cage Cone Frontface Clearance 8.6 mm
Cage Cone Backface Clearance 10.9 mm
Effective Center Location -17.5 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32248
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 490500 lbf
Static Radial Load 828000 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 127350 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 94950 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 178.84 lb
