Product Parameters

Part Number 32048X
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 240 mm x 360 mm x 76 mm
Cone Part Number X32048X
Cup Part Number Y32048X
Bore Dia 240 mm
Bore Dia Tolerance -0.03mm to 0
Outer Dia 360 mm
Outer Dia Tolerance -0.04mm to 0
Cone Width 76 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 57 mm
Cup Width Tolerance -0.25mm to 0
Width 76 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 4.06 mm
Cup Backface ToClear Radius 3.05 mm
Cone Frontface Backing Diameter 259 mm
Cone Backface Backing Diameter 268 mm
Cup Frontface Backing Diameter 346.96 mm
Cup Backface Backing Diameter 330.96 mm
Cage Cone Frontface Clearance 5.6 mm
Cage Cone Backface Clearance 9.4 mm
Effective Center Location 2.2 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32048X
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 265500 lbf
Static Radial Load 436500 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 68850 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 54225 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 56.66 lb
