Product Parameters

Part Number 32040X
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 200 mm x 310 mm x 70 mm
Cone Part Number X32040XM
Cup Part Number Y32040XM
Bore Dia 200 mm
Bore Dia Tolerance -0.03mm to 0
Outer Dia 310 mm
Outer Dia Tolerance -0.035mm to 0
Cone Width 70 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 53 mm
Cup Width Tolerance -0.25mm to 0
Width 70 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 3.05 mm
Cup Backface ToClear Radius 2.54 mm
Cone Frontface Backing Diameter 220 mm
Cone Backface Backing Diameter 225 mm
Cup Frontface Backing Diameter 297.43 mm
Cup Backface Backing Diameter 283.97 mm
Cage Cone Frontface Clearance 5.6 mm
Cage Cone Backface Clearance 7.4 mm
Effective Center Location -3.3 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 32040XM
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 190575 lbf
Static Radial Load 342000 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 49500 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 36450 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 41.23 lb
