Product Parameters

Part Number 30322
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 110 mm x 240 mm x 54.5 mm
Cone Part Number X30322M
Cup Part Number Y30322M
Bore Dia 110 mm
Bore Dia Tolerance -0.02mm to 0
Outer Dia 240 mm
Outer Dia Tolerance -0.03mm to 0
Cone Width 50 mm
Cone Width Tolerance -0.15mm to 0
Cup Width 42 mm
Cup Width Tolerance -0.25mm to 0
Width 54.5 mm
Width Tolerance +0.2mm to -0.2mm
Cone Backface ToClear Radius 4 mm
Cup Backface ToClear Radius 3 mm
Cone Frontface Backing Diameter 130 mm
Cone Backface Backing Diameter 137 mm
Cup Frontface Backing Diameter 220 mm
Cup Backface Backing Diameter 223 mm
Cage Cone Frontface Clearance 5.1 mm
Cage Cone Backface Clearance 2.8 mm
Effective Center Location -6.9 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 30322
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 129600 lbf
Static Radial Load 164700 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 33525 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 19845 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 25.35 lb
