Product Parameters

Part Number 30240
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 200 mm x 360 mm x 64 mm
Cone Part Number X30240
Cup Part Number Y30240
Bore Dia 200 mm
Bore Dia Tolerance -0.03mm to 0
Outer Dia 360 mm
Outer Dia Tolerance -0.04mm to 0
Cone Width 58 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 48 mm
Cup Width Tolerance -0.25mm to 0
Width 64 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 5.08 mm
Cup Backface ToClear Radius 0.00 mm
Cone Frontface Backing Diameter 227 mm
Cone Backface Backing Diameter 231 mm
Cup Frontface Backing Diameter 337.06 mm
Cup Backface Backing Diameter 331.00 mm
Cage Cone Frontface Clearance 9.7 mm
Cage Cone Backface Clearance 4.6 mm
Effective Center Location 7.9 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 30240
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 200475 lbf
Static Radial Load 299250 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 51975 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 38700 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 56.66 lb
