Product Parameters

Part Number 30232
Brand TFL
Interchangeable Brand Timken
System of Measurement Metric
Type Bearing
Sizes 160 mm x 290 mm x 52 mm
Cone Part Number X30232M
Cup Part Number Y30232M
Bore Dia 160 mm
Bore Dia Tolerance -0.025mm to 0
Outer Dia 290 mm
Outer Dia Tolerance -0.035mm to 0
Cone Width 48 mm
Cone Width Tolerance -0.2mm to 0
Cup Width 40 mm
Cup Width Tolerance -0.25mm to 0
Width 52 mm
Width Tolerance +0.35mm to -0.25mm
Cone Backface ToClear Radius 4 mm
Cup Backface ToClear Radius 3 mm
Cone Frontface Backing Diameter 178 mm
Cone Backface Backing Diameter 185 mm
Cup Frontface Backing Diameter 269 mm
Cup Backface Backing Diameter 266 mm
Cage Cone Frontface Clearance 6.1 mm
Cage Cone Backface Clearance 5.3 mm
Effective Center Location 5.1 mm
Bearing Type Roller
Roller Bearing Type Tapered
For Load Direction Combined
Construction Single Row
Seal Type Open
Cups Type Standard
Series 30232
Ring Material Chrome Steel
Roller Material Chrome Steel
Cage Material Steel
Dynamic Radial Load 147825 lbf
Static Radial Load 195300 lbf
Dynamic Radial Rating(90 Million Revolutions)(C90) 38250 lbf
Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 28575 lbf
Lubrication Required
Temperature Range -30° to 110 °C
ABEC Rating ABEC-1
Radial Clearance Standard (Available in C3/C4/C5)
RoHS Compliant
REACH Compliant
Weight 30.36 lb
