The S71907 CE/P4ADGA is a super precision angular contact ball bearing with a 35mm bore and 55mm outer diameter, crafted from high-grade chrome steel. Its sealed design and grease lubrication ensure smooth operation with minimal maintenance.
With a 15° contact angle, it handles both radial and thrust loads efficiently, supporting dynamic radial loads up to 2812 lbf. It spins at speeds up to 56,000 RPM, making it suitable for high-performance applications.
The phenolic cage enhances durability, while the universal matching allows flexible arrangements like back-to-back or face-to-face. Its extra-light preload ensures precision in demanding setups.
Ideal for machine tools or spindle drives, this bearing operates in temperatures from -30°C to 110°C. Weighing just 0.15kg, it’s lightweight yet robust for its size. Compliant with P4A tolerance standards for reliable performance.
"*" indicates required fields
Performance Features of S71907 CE/P4ADGA Bearing
S71907 CE/P4ADGA Bearing is designed with a 15° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls ensure durability, while the phenolic cage reduces friction and noise.
With a dynamic radial load capacity of 2812 lbf, it handles demanding conditions reliably.
The sealed design and grease lubrication minimise maintenance, extending service life.
S71907 CE/P4ADGA Bearing operates at speeds up to 56,000 rpm, balancing performance and efficiency.
Its universal matching capability allows flexible arrangement in back-to-back, face-to-face, or tandem configurations.
The P4A tolerance class ensures high precision, making it suitable for critical applications.
Its temperature range of -30°C to 110°C ensures consistent performance in varied environments.
Super Precision Angular Contact Ball Bearings S71907 CE/P4ADGA are commonly used in high-speed machine tools, where their 15° contact angle ensures accurate radial and axial load handling. The sealed design keeps contaminants out, extending service life in demanding industrial environments.
In automotive applications, S71907 CE/P4ADGA supports precision components like electric motor shafts, thanks to its universal matching capability. The extra-light preload reduces friction, making it ideal for smooth, efficient operation in hybrid and electric vehicles.
For medical imaging devices, S71907 CE/P4ADGA’s phenolic cage and chrome steel construction provide quiet, reliable performance. Its P4A tolerance class ensures the precision needed for sensitive diagnostic equipment, where even minor vibrations can affect results.
In robotics, S71907 CE/P4ADGA excels in articulated arms and joints due to its high-speed capability and matched arrangement. The grease lubrication ensures consistent performance, even in repetitive, high-precision movements required in automated systems.
