The S71905 CE/P4ADBA is a super precision angular contact ball bearing, measuring 25mm by 42mm by 18mm. Made from chrome steel with a phenolic cage, it offers reliable performance for high-speed applications.
With a 15° contact angle and sealed design, it handles radial loads up to 1960 lbf and spins smoothly at 83,000 RPM. The extra light preload ensures minimal friction during operation.
This matched set of two bearings (DB arrangement) provides excellent stability for precision machinery. It works in temperatures from -30°C to 110°C and comes pre-lubricated with grease.
Ideal for applications like machine tool spindles or high-speed motors where accuracy is key. Weighing just 0.084kg, it’s lightweight yet durable for its size.
"*" indicates required fields
Performance Features of S71905 CE/P4ADBA Bearing
S71905 CE/P4ADBA Bearing is designed with a 15° contact angle, optimising load distribution for precision tasks.
Its matched arrangement of two bearings in DB configuration ensures stability and accuracy in high-speed applications.
The phenolic cage maintains ball alignment, reducing friction and enhancing durability.
With a maximum speed of 83,000 rpm, it delivers reliable performance in demanding conditions.
Industrial Uses of S71905 CE/P4ADBA Bearing
S71905 CE/P4ADBA Bearing is commonly used in high-precision machine tools, where its angular contact design ensures accurate spindle rotation. The sealed construction helps maintain performance in environments with dust or debris.
What Makes S71905 CE/P4ADBA Bearing a Preferred Choice?
In robotics, S71905 CE/P4ADBA Bearing provides smooth motion control for articulated arms, thanks to its phenolic cage and grease lubrication. The matched arrangement reduces vibration, enhancing operational stability.
Built for Heavy-Duty Use: S71905 CE/P4ADBA Bearing
For automotive applications like electric motor systems, S71905 CE/P4ADBA Bearing handles combined radial and axial loads efficiently. Its chrome steel rings offer durability under continuous high-speed conditions.
Medical vs Industrial: Where S71905 CE/P4ADBA Bearing Excels
In medical imaging devices, S71905 CE/P4ADBA Bearing delivers quiet and precise movement, essential for diagnostic accuracy. Industrial uses include CNC machinery, where its P4A tolerance ensures repeatable precision.
