The S7005 CE/DBAVQ126 is a super precision angular contact ball bearing with a 25mm bore and 47mm outer diameter, crafted from durable chrome steel. It features a 15° contact angle and comes sealed for protection, paired as a duplex set for extra stability.
Designed for angular contact loads, it handles up to 3038 lbf dynamically and spins smoothly at speeds up to 83,000 RPM. The phenolic cage ensures quiet operation, while grease lubrication simplifies maintenance.
Its extra-light preload (Class A) and P4A tolerance make it ideal for high-precision applications like machine tool spindles or robotics. The matched pair arrangement (DB) enhances rigidity in demanding setups.
Weighing just 0.15kg, it operates reliably between -30°C to 110°C. Interchangeable with SKF bearings, it’s a practical choice for replacements or upgrades in precision machinery.
"*" indicates required fields
Why Choose S7005 CE/DBAVQ126 Bearing for Precision Tasks?
S7005 CE/DBAVQ126 Bearing features a 15° contact angle, optimised for high-precision angular contact applications.
Its matched arrangement of two bearings ensures stability and accuracy in demanding conditions.
The chrome steel rings and balls provide durability, while the phenolic cage reduces friction and wear.
With a dynamic radial load capacity of 3038 lbf, it handles rigorous operations with ease.
S7005 CE/DBAVQ126 Bearing operates smoothly at speeds up to 83,000 rpm, thanks to its grease lubrication.
Its P4A tolerance class guarantees consistent performance for precision engineering needs.
Key Fields for S7005 CE/DBAVQ126 Bearing
S7005 CE/DBAVQ126 Bearing is commonly used in high-speed machine tools, where its precision angular contact design ensures accurate spindle rotation. The sealed construction helps maintain performance in environments with dust or debris.
In automotive applications, S7005 CE/DBAVQ126 Bearing supports components like electric motors and gearboxes, thanks to its extra light preload and matched arrangement. The phenolic cage reduces friction, enhancing efficiency in high-speed scenarios.
For robotics, S7005 CE/DBAVQ126 Bearing’s 15° contact angle provides stability in articulated arms and joints. Its P4A tolerance class ensures consistent performance in repetitive motion tasks.
In medical imaging devices, S7005 CE/DBAVQ126 Bearing’s grease lubrication and chrome steel construction offer quiet, reliable operation. The temperature range suits both clinical and laboratory settings.
