The S7002 CE/P4A is a super precision angular contact ball bearing with a compact size of 15mm by 32mm by 9mm, crafted from durable chrome steel. It features a 15° contact angle and comes sealed for protection, with matched sets and preload options available.
This bearing handles radial loads up to 994 lbf and spins at speeds up to 68,000 RPM, making it suitable for high-performance applications. The phenolic cage ensures smooth operation and reduces friction.
Its P4 tolerance class (ABEC-7) guarantees high precision, ideal for demanding tasks. The sealed design keeps lubrication in and contaminants out, extending its lifespan.
Perfect for precision machinery like spindles or high-speed tools, it operates in temperatures from -30°C to 110°C. Weighing just 0.029kg, it’s lightweight yet robust. Interchangeable with SKF bearings, it’s a reliable choice for replacements.
"*" indicates required fields
Performance Features of S7002 CE/P4A Bearing
S7002 CE/P4A Bearing is designed with a 15° contact angle, optimising load distribution for angular contact applications.
Its chrome steel rings and balls ensure durability, while the phenolic cage reduces friction and noise.
With a dynamic radial load capacity of 994 lbf, S7002 CE/P4A Bearing handles high-speed operations up to 68,000 rpm.
The sealed design and preload availability enhance performance in precision tasks.
S7002 CE/P4A Bearing operates efficiently within a temperature range of -30° to 110°C.
Its P4 tolerance class guarantees high precision, making it suitable for demanding industrial uses.
The lubricated design ensures smooth operation, reducing maintenance needs.
S7002 CE/P4A Bearing’s compact size (15 mm×32 mm×9 mm) allows for versatile installation in tight spaces.
Key Fields for S7002 CE/P4A Bearing
S7002 CE/P4A Bearing is commonly used in high-precision machine tools, where its angular contact design ensures accurate spindle rotation. The sealed construction helps maintain performance in environments with dust or debris.
In automotive applications, S7002 CE/P4A Bearing supports components like electric power steering systems, thanks to its reliable load handling. Its phenolic cage also reduces friction, enhancing efficiency.
For medical imaging devices, S7002 CE/P4A Bearing’s P4 tolerance class provides the precision needed for smooth operation. The chrome steel construction ensures durability even with frequent use.
Automation systems benefit from S7002 CE/P4A Bearing’s matched arrangement, which simplifies installation in robotic arms. Its high-speed capability makes it suitable for repetitive tasks.
In consumer electronics, S7002 CE/P4A Bearing can be found in high-end printers, where quiet operation is essential. The lubricated design helps extend its service life.
